ZE550EK-10 Zoomlion excavator specs & Dimensions (2021 - 2026)

Zoomlion ZE550EK-10 is a crawler excavator manufactured since 2021. It has a weight of 53.5 tons and a track width of 600 mm. The …

Zoomlion ZE550EK-10 is a crawler excavator manufactured since 2021. It has a weight of 53.5 tons and a track width of 600 mm. The transport dimensions are 11.715 meters in length, 3.61 meters in width, and 4.172 meters in height. The excavator features a tear-out force of 315 kN, a dredging depth of 6.57 meters, and a maximum horizontal reach of 10.68 meters. The bucket capacity is up to 2.85 cubic meters.

Crawler Excavators Zoomlion ZE550EK-10

Technical specs - ZE550EK-10 Zoomlion

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
53.5 t
Transport length
11.715 m
Transport width
3.61 m
Transport height
4.172 m
Bucket capacity max.
2.85 m³
Track width
600 mm
Max. Reach horizontal
10.68 m
Dredging depth
6.57 m
Tear-out force
315 kN
Model series
ZE
Engine manuf.
Cummins
Engine type
QSM11
Engine power
300 kW
Displacement
10.8 l
Emission level
Stage IIIA

More technical details, like: bucket capacity, bucket capacity min., undercarriage, boom, bucket width, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Zoomlion ZE550EK-10 FAQ

When was the Zoomlion ZE550EK-10 manufactured?

The Zoomlion ZE550EK-10 was first produced in 2021.

How much does the Zoomlion ZE550EK-10 weigh?

The Zoomlion ZE550EK-10 weighs 53.5 tons.

What are the transport dimensions of the Zoomlion ZE550EK-10?

The Zoomlion ZE550EK-10 has a transport length of 11.72 meters, a transport width of 3.61 meters, and a transport height of 4.17 meters.

What is the track width of the Zoomlion ZE550EK-10's undercarriage?

The Zoomlion ZE550EK-10 has a track width of 600 mm.

What are the excavation performance specifications of the Zoomlion ZE550EK-10?

The Zoomlion ZE550EK-10 has a dredging depth of 6.57 meters and a maximum horizontal reach of 10.68 meters.

What are the power ratings of the Zoomlion ZE550EK-10?

There is no power rating data available for the Zoomlion ZE550EK-10 in the provided information.

What is the maximum bucket capacity of the Zoomlion ZE550EK-10?

The maximum bucket capacity of the Zoomlion ZE550EK-10 is 2.85 cubic meters.

How much is a Zoomlion ZE550EK-10 Crawler excavator (2021u20132025) worth?

The residual value of the Zoomlion ZE550EK-10 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
