EC340 Volvo excavator specs & Dimensions (1998 - 1999)

Volvo EC340 is a crawler excavator manufactured from 1998 to 1999, with a weight of 36.7 tons. It features a track width of 600 mm…

Volvo EC340 is a crawler excavator manufactured from 1998 to 1999, with a weight of 36.7 tons. It features a track width of 600 mm, a transport length of 11.2 meters, a transport width of 3.6 meters, and a transport height of 3.48 meters. The machine has a tear-out force of 259 kN, a dredging depth of 7.2 meters, a maximum horizontal reach of 10.9 meters, and a bucket capacity of 2.7 cubic meters.

Crawler Excavators Volvo EC340

Visit Volvo live at

Technical specs - EC340 Volvo

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
36.7 t
Transport length
11.2 m
Transport width
3.6 m
Transport height
3.48 m
Bucket capacity
2.7 m³
Track width
600 mm
Max. Reach horizontal
10.9 m
Dredging depth
7.2 m
Tear-out force
259 kN
Engine manuf.
Volvo
Engine type
TD 103 KAE
Engine power
190 kW
Displacement
9.6 l
Revolutions at max torque
1700 rpm
No. of cylinders
6
Cylinder bore x stroke
120.65x140 mm

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, boom, bucket width, model series, dimension lxwxh, max. torque, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Volvo EC340 FAQ

When was the Volvo EC340 manufactured?

The Volvo EC340 was manufactured from 1998 to 1999.

How much does the Volvo EC340 weigh?

The Volvo EC340 weighs 36.7 tons.

What are the transport dimensions of the Volvo EC340 crawler excavator?

The Volvo EC340 has a transport length of 11.2 meters, a transport width of 3.6 meters, and a transport height of 3.48 meters.

What is the track width of the Volvo EC340's undercarriage?

The Volvo EC340 has a track width of 600 mm on its undercarriage.

What are the excavation performance specifications of the Volvo EC340?

The Volvo EC340 has a dredging depth of 7.2 meters and a maximum horizontal reach of 10.9 meters.

What is the power rating of the Volvo EC340?

The power rating information for the Volvo EC340 is not available in the provided data.

What is the bucket capacity of the Volvo EC340 excavator?

The Volvo EC340 excavator has a bucket capacity of 2.7 cubic meters.

How much is a Volvo EC340 Crawler excavator (1998u20131999) worth?

The residual value of the Volvo EC340 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
