EC300EL Volvo excavator specs & Dimensions (2019 - 2026)

Volvo EC300EL is a crawler excavator manufactured since 2019. It has a weight of 29.75 tons, a transport length of 10.61 meters, a…

Volvo EC300EL is a crawler excavator manufactured since 2019. It has a weight of 29.75 tons, a transport length of 10.61 meters, a transport width of 3.19 meters, and a transport height of 3.51 meters. The machine features a tear-out force of 188 kN, a dredging depth of 6.84 meters, and a maximum horizontal reach of 10.18 meters. The bucket capacity is 1.209 cubic meters. Special equipment includes air conditioning and a blade.

Crawler Excavators Volvo EC300EL
Crawler Excavators Volvo EC300EL
Crawler Excavators Volvo EC300EL
Crawler Excavators Volvo EC300EL
Crawler Excavators Volvo EC300EL
Crawler Excavators Volvo EC300EL
Crawler Excavators Volvo EC300EL
Crawler Excavators Volvo EC300EL
Crawler Excavators Volvo EC300EL
Crawler Excavators Volvo EC300EL
Crawler Excavators Volvo EC300EL
Crawler Excavators Volvo EC300EL
Crawler Excavators Volvo EC300EL
Crawler Excavators Volvo EC300EL

Visit Volvo live at

Technical specs - EC300EL Volvo

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
29.75 t
Transport length
10.61 m
Transport width
3.19 m
Transport height
3.51 m
Bucket capacity
1.209 m³
Boom
MB
Max. Reach horizontal
10.18 m
Dredging depth
6.84 m
Tear-out force
188 kN
Model series
EC
Engine manuf.
Volvo
Engine type
D8J
Engine power
179 kW
Displacement
7.8 l
Revolutions at max torque
1800 rpm
Max. torque
1238/1350 Nm
No. of cylinders
6
Cylinder bore x stroke
110x136 mm
Emission level
V

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, track width, bucket width, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Volvo EC300EL FAQ

When was the Volvo EC300EL manufactured?

The Volvo EC300EL was first produced in 2019.

How much does the Volvo EC300EL weigh?

The Volvo EC300EL weighs 29.75 tons.

What are the transport dimensions of the Volvo EC300EL crawler excavator?

The Volvo EC300EL has a transport length of 10.61 meters, a transport width of 3.19 meters, and a transport height of 3.51 meters.

What is the fuel consumption range of the Volvo EC300EL?

The Volvo EC300EL has a fuel consumption range of 13 to 25 liters per hour.

What are the excavation performance specifications of the Volvo EC300EL?

The Volvo EC300EL has a dredging depth of 6.84 meters, a maximum horizontal reach of 10.18 meters, and is equipped with a monobloc boom.

What is the tear-out force of the Volvo EC300EL?

The Volvo EC300EL has a tear-out force of 188 kN.

What is the bucket capacity of the Volvo EC300EL excavator?

The bucket capacity of the Volvo EC300EL excavator is 1.209 cubic meters.

How much is a Volvo EC300EL Crawler excavator (2019u20132025) worth?

The residual value of the Volvo EC300EL depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
