SWE385ES Sunward excavator specs & Dimensions (2020 - 2025)

Sunward SWE385ES is a crawler excavator manufactured since 2020. It has a weight of 38.5 tons and a track width of 600 mm. The tra…

Sunward SWE385ES is a crawler excavator manufactured since 2020. It has a weight of 38.5 tons and a track width of 600 mm. The transport dimensions are 11.3 meters in length, 3.34 meters in width, and 3.5 meters in height. The machine features a tear-out force of 253 kN, a dredging depth of 7.07 meters, and a maximum horizontal reach of 10.73 meters. The bucket width is 1.34 meters with a capacity of 1.6 cubic meters.

Crawler Excavators Sunward SWE385ES

Technical specs - SWE385ES Sunward

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
38.5 t
Transport length
11.3 m
Transport width
3.34 m
Transport height
3.5 m
Bucket capacity
1.6 m³
Track width
600 mm
Max. Reach horizontal
10.73 m
Dredging depth
7.07 m
Tear-out force
253 kN
Bucket width
1.34 m
Model series
SWE
Engine manuf.
Cummins
Engine type
QSL9
Engine power
222 kW
Displacement
8.9 l
Revolutions at max torque
1400 rpm
Max. torque
1505 Nm
No. of cylinders
6
Cylinder bore x stroke
114x145 mm

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, boom, dimension lxwxh, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Sunward SWE385ES FAQ

When was the Sunward SWE385ES manufactured?

The Sunward SWE385ES was first produced in 2020.

How much does the Sunward SWE385ES weigh?

The Sunward SWE385ES weighs 38.5 tons.

What are the transport dimensions of the Sunward SWE385ES crawler excavator?

The Sunward SWE385ES has a transport length of 11.3 meters, a transport width of 3.34 meters, and a transport height of 3.5 meters.

What is the track width of the Sunward SWE385ES's undercarriage?

The Sunward SWE385ES has a track width of 600 mm.

What are the excavation performance specifications of the Sunward SWE385ES?

The Sunward SWE385ES has a dredging depth of 7.07 meters and a maximum horizontal reach of 10.73 meters.

What is the power rating of the Sunward SWE385ES?

The source data does not provide power rating information for the Sunward SWE385ES.

What are the specifications of the bucket on the Sunward SWE385ES crawler excavator?

The bucket of the Sunward SWE385ES has a capacity of 1.6 cubic meters and a width of 1.34 meters.

How much is a Sunward SWE385ES Crawler excavator (2020u20132025) worth?

The residual value of the Sunward SWE385ES depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
