E75C SR LC New Holland excavator specs & Dimensions (2012 - 2015)

New Holland E75C SR LC is a Crawler Excavator manufactured from 2012 to 2015, with a weight of 8.7 tons. It features a track width…

New Holland E75C SR LC is a Crawler Excavator manufactured from 2012 to 2015, with a weight of 8.7 tons. It features a track width of 450 mm, a transport length of 5.78 meters, a transport width of 2.47 meters, and a transport height of 2.6 meters. The excavator has a tear-out force of 53 kN, a dredging depth of 3.74 meters, and a maximum horizontal reach of 7.18 meters. It comes with a bucket width of 0.85 meters and a bucket capacity of 0.36 cubic meters. Special equipment includes air conditioning and an overload alert system.

Crawler Excavators New Holland E75C SR LC
Crawler Excavators New Holland E75C SR LC
Crawler Excavators New Holland E75C SR LC
Crawler Excavators New Holland E75C SR LC
Crawler Excavators New Holland E75C SR LC
Crawler Excavators New Holland E75C SR LC
Crawler Excavators New Holland E75C SR LC
Crawler Excavators New Holland E75C SR LC
Crawler Excavators New Holland E75C SR LC
Crawler Excavators New Holland E75C SR LC

Technical specs - E75C SR LC New Holland

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
8.7 t
Transport length
5.78 m
Transport width
2.47 m
Transport height
2.6 m
Bucket capacity
0.36 m³
Undercarriage
LC
Track width
450 mm
Boom
SKA
Max. Reach horizontal
7.18 m
Dredging depth
3.74 m
Tear-out force
53 kN
Bucket width
0.85 m
Model series
E
Engine manuf.
Isuzu
Engine type
AU-4LE2X
Engine power
42 kW
Displacement
2.2 l
Revolutions at max torque
2000 rpm

More technical details, like: bucket capacity min., bucket capacity max., dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

New Holland E75C SR LC FAQ

When was the New Holland E75C SR LC manufactured?

The New Holland E75C SR LC was manufactured from 2012 to 2015.

How much does the New Holland E75C SR LC weigh?

The New Holland E75C SR LC weighs 8.7 tons.

What are the transport dimensions of the New Holland E75C SR LC crawler excavator?

The New Holland E75C SR LC has transport dimensions of 5.78 meters in length, 2.47 meters in width, and 2.6 meters in height.

What are the undercarriage specifications of the New Holland E75C SR LC?

The New Holland E75C SR LC has a long undercarriage and a track width of 450 mm.

What are the excavation performance specifications of the New Holland E75C SR LC?

The New Holland E75C SR LC has a dredging depth of 3.74 meters, a maximum horizontal reach of 7.18 meters, and features a lateral articulated boom.

What is the power rating of the New Holland E75C SR LC?

The source data does not provide a power rating for the New Holland E75C SR LC. It only specifies a tear-out force of 53 kN.

What are the specifications of the primary work tool on the New Holland E75C SR LC?

The primary work tool of the New Holland E75C SR LC has a bucket capacity of 0.36 cubic meters and a bucket width of 0.85 meters.
