E265C LC New Holland excavator specs & Dimensions (2011 - 2015)

New Holland E265C LC is a Crawler Excavator manufactured from 2011 to 2015. It has a weight of 27.9 tons and a track width of 600 …

New Holland E265C LC is a Crawler Excavator manufactured from 2011 to 2015. It has a weight of 27.9 tons and a track width of 600 mm. The transport dimensions are 10.39 meters in length, 3.2 meters in width, and 3.445 meters in height. The excavator features a tear-out force of 190 kN, a dredging depth of 6.8 meters, and a maximum horizontal reach of 10.3 meters. The bucket width is 1.7 meters with a capacity of 1.4 cubic meters. Special equipment includes air conditioning and an overload alert system.

Crawler Excavators New Holland E265C LC
Crawler Excavators New Holland E265C LC
Crawler Excavators New Holland E265C LC
Crawler Excavators New Holland E265C LC

Technical specs - E265C LC New Holland

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
27.9 t
Transport length
10.39 m
Transport width
3.2 m
Transport height
3.445 m
Bucket capacity
1.4 m³
Undercarriage
LC
Track width
600 mm
Boom
MB
Max. Reach horizontal
10.3 m
Dredging depth
6.8 m
Tear-out force
190 kN
Bucket width
1.7 m
Model series
E
Engine manuf.
CNH
Engine type
F4HFE613S-A004
Engine power
142 kW
Displacement
6.7 l
Revolutions at max torque
2000 rpm

More technical details, like: bucket capacity min., bucket capacity max., dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

New Holland E265C LC FAQ

When was the New Holland E265C LC manufactured?

The New Holland E265C LC was manufactured from 2011 to 2015.

How much does the New Holland E265C LC weigh?

The New Holland E265C LC weighs 27.9 tons.

What are the transport dimensions of the New Holland E265C LC crawler excavator?

The New Holland E265C LC has a transport length of 10.39 meters, a transport width of 3.2 meters, and a transport height of 3.45 meters.

What are the undercarriage specifications of the New Holland E265C LC?

The New Holland E265C LC has a long undercarriage with a track width of 600 mm.

What are the excavation performance specifications of the New Holland E265C LC?

The New Holland E265C LC has a dredging depth of 6.8 meters, a maximum horizontal reach of 10.3 meters, and is equipped with a Monobloc boom.

What is the tear-out force of the New Holland E265C LC?

The New Holland E265C LC has a tear-out force of 190 kN.

What are the specifications of the primary work tool bucket on the New Holland E265C LC?

The primary work tool bucket of the New Holland E265C LC has a capacity of 1.4 cubic meters and a width of 1.7 meters.

How much is a New Holland E265C LC Crawler excavator (2011u20132015) worth?

The residual value of the New Holland E265C LC depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
