E160 New Holland excavator specs & Dimensions (2005 - 2026)

New Holland E160 is a crawler excavator manufactured since 2005. It has a weight of 16 tons and a track width of 600 mm. The trans…

New Holland E160 is a crawler excavator manufactured since 2005. It has a weight of 16 tons and a track width of 600 mm. The transport dimensions are 8 meters in length, 2 meters in width, and 2 meters in height. The machine features a tear-out force of 124 kN, a dredging depth of 6 meters, and a maximum horizontal reach of 9 meters. The bucket capacity is up to 1 cubic meter. Special equipment includes air conditioning, cabin adjustment, a diesel particulate filter, and track adjustment.

Crawler Excavators New Holland E160

Technical specs - E160 New Holland

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
16.7 t
Transport length
8.65 m
Transport width
2.59 m
Transport height
2.96 m
Bucket capacity min.
0.34 m³
Bucket capacity max.
1.04 m³
Undercarriage
HD
Track width
600 mm
Boom
MB
Max. Reach horizontal
9.5 m
Dredging depth
6.57 m
Tear-out force
124.54 kN
Engine manuf.
Mitsubishi
Engine type
4D34-TEG
Engine power
82 kW
Displacement
3.91 l
No. of cylinders
6
Cylinder bore x stroke
104 x 115 mm
Emission level
Tier 2

More technical details, like: bucket capacity, bucket width, model series, dimension lxwxh, revolutions at max torque, max. torque are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
Yes
Blade
No
Cabin adjustment
Yes
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

New Holland E160 FAQ

When was the New Holland E160 manufactured?

The New Holland E160 was first produced in 2005.

How much does the New Holland E160 weigh?

The New Holland E160 weighs 16.7 tons.

What are the transport dimensions of the New Holland E160 crawler excavator?

The New Holland E160 has a transport length of 8.65 meters, a transport width of 2.59 meters, and a transport height of 2.96 meters.

What are the undercarriage specifications of the New Holland E160?

The New Holland E160 has a heavy duty undercarriage with a track width of 600 mm.

What are the excavation performance specifications of the New Holland E160?

The New Holland E160 has a dredging depth of 6.57 meters, a maximum horizontal reach of 9.5 meters, and is equipped with a monobloc boom.

What is the tear-out force of the New Holland E160?

The New Holland E160 has a tear-out force of 124.54 kN.

What is the maximum bucket capacity of the New Holland E160?

The New Holland E160 has a maximum bucket capacity of 1.04 cubic meters.

How much is a New Holland E160 Crawler excavator (2005u20132025) worth?

The residual value of the New Holland E160 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

New Holland E160 overview

Hydraulic and electronic system

The information you need

This in-cab monitor displays vital functions with an engine tachometer, fuel gauge and engine temperature gauge. Warning and status indicators include low engine oil pressure, low fuel level, air cleaner restriction, engine preheating, battery charging and CPU error. Maintenance interval indicators are also provided for engine oil, fuel filter, hydraulic oil and hydraulic filter change.


Undercarriage

Independent Travel System

Lifting and carrying objects is a very sensitive operation, requiring much skill. The Independent Travel System (on models E160 and E215) makes these tasks easier by reducing the need to “feather” the controls. Since a separate pump is exclusively dedicated to the travel system, the excavators don’t lose speed when raising the load while traveling.
