E 80 MSR New Holland excavator specs & Dimensions (2003 - 2007)

Model rating
8,50 / 10

New Holland E 80 MSR is a crawler excavator manufactured from 2003 to 2007, with a weight of 8.3 tons. It has a transport length o…

New Holland E 80 MSR is a crawler excavator manufactured from 2003 to 2007, with a weight of 8.3 tons. It has a transport length of 6.76 meters, a transport width of 2.32 meters, and a transport height of 2.6 meters. The excavator is equipped with special equipment including a blade and a hydraulic quick hitch.

Crawler Excavators New Holland E 80 MSR

Technical specs - E 80 MSR New Holland

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
8.3 t
Transport length
6.76 m
Transport width
2.32 m
Transport height
2.6 m
Bucket capacity
0.35 m³
Track width
450 mm
Boom
MB
Max. Reach horizontal
7.5 m
Dredging depth
4.52 m
Tear-out force
36 kN
Model series
E
Engine manuf.
Isuzu
Engine type
CC-4JG1
Engine power
40.5 kW
Displacement
3.059 l
Revolutions at max torque
1800 rpm

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, bucket width, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

New Holland E 80 MSR FAQ

When was the New Holland E 80 MSR manufactured?

The New Holland E 80 MSR was manufactured from 2003 to 2007.

How much does the New Holland E 80 MSR weigh?

The New Holland E 80 MSR weighs 8.3 tons.

What are the transport dimensions of the New Holland E 80 MSR?

The New Holland E 80 MSR has a transport length of 6.76 meters, a transport width of 2.32 meters, and a transport height of 2.6 meters.

What is the track width of the New Holland E 80 MSR's undercarriage?

The New Holland E 80 MSR has a track width of 450 mm.

What are the excavation performance specifications of the New Holland E 80 MSR?

The New Holland E 80 MSR has a dredging depth of 4.52 meters, a maximum horizontal reach of 7.5 meters, and is equipped with a monobloc boom.

What is the tear-out force of the New Holland E 80 MSR?

The New Holland E 80 MSR has a tear-out force of 36 kN. No power rating data is available for this model in the provided source.

What is the bucket capacity of the New Holland E 80 MSR excavator?

The bucket capacity of the New Holland E 80 MSR is 0.35 cubic meters.

How much is a New Holland E 80 MSR Crawler excavator (2003u20132007) worth?

The residual value of the New Holland E 80 MSR depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Reviews

Model rating
8,50 / 10
Quotation mark

New Holland E 80 MSR user from Latvia

It's ergonomic, easy to use and easy service. Fuel economy is above avarage, 7000mh and no serious problems.
