E 70 B SR New Holland excavator specs & Dimensions (2008 - 2012)

New Holland E 70 B SR is a crawler excavator manufactured from 2008 to 2012, with a weight of 8.05 tons. It has a transport length…

New Holland E 70 B SR is a crawler excavator manufactured from 2008 to 2012, with a weight of 8.05 tons. It has a transport length of 5.78 meters, a transport width of 2.47 meters, and a transport height of 2.6 meters. This model is equipped with a diesel particulate filter.

Crawler Excavators New Holland E 70 B SR

Technical specs - E 70 B SR New Holland

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
8.05 t
Transport length
5.78 m
Transport width
2.47 m
Transport height
2.6 m
Bucket capacity
0.36 m³
Undercarriage
SL
Track width
450 mm
Max. Reach horizontal
7.14 m
Dredging depth
3.42 m
Tear-out force
5.5 kN
Bucket width
0.85 m
Model series
E
Engine manuf.
Isuzu
Engine type
AU-4LE2X
Engine power
42 kW
Displacement
2.2 l
Revolutions at max torque
2000 rpm

More technical details, like: bucket capacity min., bucket capacity max., boom, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

New Holland E 70 B SR FAQ

When was the New Holland E 70 B SR manufactured?

The New Holland E 70 B SR was manufactured from 2008 to 2012.

How much does the New Holland E 70 B SR weigh?

The New Holland E 70 B SR weighs 8.05 tons.

What are the transport dimensions of the New Holland E 70 B SR crawler excavator?

The New Holland E 70 B SR has a transport length of 5.78 meters, a transport width of 2.47 meters, and a transport height of 2.6 meters.

What are the undercarriage specifications of the New Holland E 70 B SR?

The New Holland E 70 B SR has a standard undercarriage with a track width of 450 mm.

What are the excavation performance specifications of the New Holland E 70 B SR?

The New Holland E 70 B SR has a dredging depth of 3.42 meters and a maximum horizontal reach of 7.14 meters.

What are the power ratings of the New Holland E 70 B SR?

The source data does not provide power rating information for the New Holland E 70 B SR.

What are the bucket specifications of the New Holland E 70 B SR excavator?

The New Holland E 70 B SR excavator has a bucket capacity of 0.36 cubic meters and a bucket width of 0.85 meters.
