950E Liugong excavator specs & Dimensions (2017 - 2026)

Liugong 950E is a Crawler Excavator manufactured since 2017, with a weight of 46.5 tons. It features a track width of 600 mm, a tr…

Liugong 950E is a Crawler Excavator manufactured since 2017, with a weight of 46.5 tons. It features a track width of 600 mm, a transport length of 11.515 meters, a transport width of 3.34 meters, and a transport height of 3.81 meters. The machine has a tear-out force of 265 kN, a dredging depth of 6.521 meters, and a maximum horizontal reach of 10.625 meters. The bucket width is 1.9 meters, with a bucket capacity of 3.2 cubic meters. It is equipped with air conditioning.

Crawler Excavators Liugong 950E

Visit Liugong live at

Technical specs - 950E Liugong

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
46.5 t
Transport length
11.515 m
Transport width
3.34 m
Transport height
3.81 m
Bucket capacity
3.2 m³
Track width
600 mm
Boom
MB
Max. Reach horizontal
10.625 m
Dredging depth
6.521 m
Tear-out force
265 kN
Bucket width
1.9 m
Model series
E
Engine manuf.
Cummins
Engine type
QSM11
Engine power
260 kW
Displacement
10.8 l
Revolutions at max torque
2100 rpm
Max. torque
1898/1400 Nm
No. of cylinders
6
Cylinder bore x stroke
125x147 mm
Emission level
Tier 3/EU IIIA

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Liugong 950E FAQ

When was the Liugong 950E manufactured?

The Liugong 950E was first produced in 2017.

How much does the Liugong 950E weigh?

The Liugong 950E weighs 46.5 tons.

What are the transport dimensions of the Liugong 950E crawler excavator?

The Liugong 950E has a transport length of 11.52 meters, a transport width of 3.34 meters, and a transport height of 3.81 meters.

What is the track width of the Liugong 950E's undercarriage?

The Liugong 950E has a track width of 600 mm.

What are the excavation performance specifications of the Liugong 950E?

The Liugong 950E has a dredging depth of 6.521 meters, a maximum horizontal reach of 10.625 meters, and is equipped with a monobloc boom.

What are the power ratings of the Liugong 950E crawler excavator?

The source data does not provide any power ratings for the Liugong 950E crawler excavator.

What are the specifications of the primary work tool bucket on the Liugong 950E?

The Liugong 950E has a bucket with a capacity of 3.2 cubic meters and a width of 1.9 meters.

How much is a Liugong 950E Crawler excavator (2017u20132025) worth?

The residual value of the Liugong 950E depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
