936E Liugong excavator specs & Dimensions (2018 - 2026)

Liugong 936E is a Crawler Excavator manufactured since 2018, with a weight of 35 tons. It features a track width of 600 mm, a tran…

Liugong 936E is a Crawler Excavator manufactured since 2018, with a weight of 35 tons. It features a track width of 600 mm, a transport length of 11.167 meters, a transport width of 3.19 meters, and a transport height of 3.53 meters. The excavator has a tear-out force of 232 kN, a dredging depth of 7.34 meters, and a maximum horizontal reach of 11.1 meters. It comes with a bucket width of 1.52 meters and a bucket capacity of 1.6 cubic meters. Special equipment includes air conditioning.

Crawler Excavators Liugong 936E

Technical specs - 936E Liugong

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
35 t
Transport length
11.167 m
Transport width
3.19 m
Transport height
3.53 m
Bucket capacity
1.6 m³
Track width
600 mm
Boom
MB
Max. Reach horizontal
11.1 m
Dredging depth
7.34 m
Tear-out force
232 kN
Bucket width
1.52 m
Model series
E
Engine manuf.
Cummins
Engine type
QSL9
Engine power
202 kW
Displacement
8.9 l
Revolutions at max torque
2100 rpm
Max. torque
1343/1500 Nm
No. of cylinders
6
Cylinder bore x stroke
114x145 mm
Emission level
Tier 3/EU IIIA

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Liugong 936E FAQ

When was the Liugong 936E manufactured?

The Liugong 936E was first produced in 2018.

How much does the Liugong 936E weigh?

The Liugong 936E weighs 35 tons.

What are the transport dimensions of the Liugong 936E crawler excavator?

The Liugong 936E has a transport length of 11.17 meters, a transport width of 3.19 meters, and a transport height of 3.53 meters.

What is the track width of the Liugong 936E crawler excavator?

The Liugong 936E crawler excavator has a track width of 600 mm.

What are the excavation performance specifications of the Liugong 936E crawler excavator?

The Liugong 936E crawler excavator has a dredging depth of 7.34 meters, a maximum horizontal reach of 11.1 meters, and is equipped with a monobloc boom.

What are the power ratings of the Liugong 936E crawler excavator?

There are no power rating specifications available for the Liugong 936E crawler excavator in the provided data.

What are the specifications of the primary work tool on the Liugong 936E?

The Liugong 936E has a bucket with a capacity of 1.6 cubic meters and a width of 1.52 meters.

How much is a Liugong 936E Crawler excavator (2018u20132025) worth?

The residual value of the Liugong 936E depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
