460 LX Link-Belt excavator specs & Dimensions (2002 - 2023)

Link-Belt 460 LX is a crawler excavator manufactured since 2002, with a weight of 47 tons. It features a track width of 900 mm, a …

Link-Belt 460 LX is a crawler excavator manufactured since 2002, with a weight of 47 tons. It features a track width of 900 mm, a transport length of 12 meters, a transport width of 3 meters, and a transport height of 4 meters. The bucket width is 1.676 meters, with a bucket capacity ranging from 1 m³ to 3 m³. Special equipment includes air conditioning and a diesel particulate filter.

Crawler Excavators Link-Belt 460 LX

Technical specs - 460 LX Link-Belt

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
47 t
Transport length
12 m
Transport width
3 m
Transport height
4 m
Bucket capacity min.
1 m³
Bucket capacity max.
3 m³
Undercarriage
LC
Track width
900 mm
Boom
MB
Max. Reach horizontal
13.4 m
Dredging depth
9.2 m
Tear-out force
269.98 kN
Bucket width
1.676 m
Engine manuf.
Isuzu
Engine type
AA-6SDl XQB
Engine power
235 kW
Displacement
9.839 l
Revolutions at max torque
1600 rpm
Max. torque
1275 Nm
No. of cylinders
6
Cylinder bore x stroke
120 x 145 mm
Emission level
Tier 2

More technical details, like: bucket capacity, model series, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Link-Belt 460 LX FAQ

When was the Link-Belt 460 LX manufactured?

The Link-Belt 460 LX was manufactured from 2002 to 2023.

How much does the Link-Belt 460 LX weigh?

The Link-Belt 460 LX weighs 47 tons.

What are the transport dimensions of the Link-Belt 460 LX?

The Link-Belt 460 LX has a transport length of 12 meters, a transport width of 3 meters, and a transport height of 4 meters.

What are the undercarriage specifications of the Link-Belt 460 LX?

The Link-Belt 460 LX has a long undercarriage and a track width of 900 mm.

What are the excavation performance specifications of the Link-Belt 460 LX?

The Link-Belt 460 LX has a dredging depth of 9.2 meters, a maximum horizontal reach of 13.4 meters, and features a monobloc boom.

What are the power ratings of the Link-Belt 460 LX?

The source data does not provide any power ratings for the Link-Belt 460 LX.

What are the specifications of the primary work tool bucket on the Link-Belt 460 LX?

The primary work tool bucket of the Link-Belt 460 LX has a maximum capacity of 3 cubic meters, a minimum capacity of 1 cubic meter, and a width of 1.676 meters.

How much is a Link-Belt 460 LX Crawler excavator (2002u20132023) worth?

The residual value of the Link-Belt 460 LX depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
