360 X4 Link-Belt excavator specs & Dimensions (2026 - 2026)

Weight: 37.8t – Transport length: 11.25m – Transport width: 3.59m – Transport height: 3.63m – Track width: 600mm – Max. Reach hori…

Weight: 37.8t – Transport length: 11.25m – Transport width: 3.59m – Transport height: 3.63m – Track width: 600mm – Max. Reach horizontal: 10.98m

Check out detailed specifications, information and technical data for Link-Belt 360 X4 excavator manufactured between 2026 - 2026. Get more in-depth insight with Link-Belt 360 X4 digger specifications. See information, like: Weight: 37.8t – Transport length: 11.25m – Transport width: 3.59m – Transport height: 3.63m – Track width: 600mm – Max. Reach horizontal: 10.98m and more.

Technical specs - 360 X4 Link-Belt

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
37.8 t
Transport length
11.25 m
Transport width
3.59 m
Transport height
3.63 m
Track width
600 mm
Max. Reach horizontal
10.98 m
Dredging depth
7.34 m
Model series
X4
Engine manuf.
Isuzu
Engine type
AQ-6HK1X
Engine power
200 kW
Displacement
7.8 l
Revolutions at max torque
1500 rpm
Max. torque
988 Nm
No. of cylinders
6
Emission level
Tier 4 final

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., undercarriage, boom, tear-out force, bucket width, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No
