R 964 Litronic Liebherr excavator specs & Dimensions (2012 - 2013)

Liebherr R 964 Litronic is a crawler excavator manufactured from 2012 to 2013. It has a weight of 38.6 tons and a track width of 6…

Liebherr R 964 Litronic is a crawler excavator manufactured from 2012 to 2013. It has a weight of 38.6 tons and a track width of 600 mm. The transport dimensions are 11.3 meters in length, 3.185 meters in width, and 3.25 meters in height. The machine features a tear-out force of 191 kN and a dredging depth of 7 meters. It is equipped with air conditioning.

Crawler Excavators Liebherr R 964 Litronic

Visit Liebherr live at

Technical specs - R 964 Litronic Liebherr

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
38.6 t
Transport length
11.3 m
Transport width
3.185 m
Transport height
3.25 m
Bucket capacity
1.8 m³
Undercarriage
LC
Track width
600 mm
Boom
MB
Max. Reach horizontal
10.9 m
Dredging depth
7 m
Tear-out force
191 kN
Bucket width
1.5 m
Model series
R
Engine manuf.
Liebherr
Engine type
D 936 A 7
Engine power
200 kW
Displacement
10.52 l
Revolutions at max torque
1800 rpm
Emission level
IIIB

More technical details, like: bucket capacity min., bucket capacity max., dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Liebherr R 964 Litronic FAQ

When was the Liebherr R 964 Litronic manufactured?

The Liebherr R 964 Litronic was manufactured from 2012 to 2013.

How much does the Liebherr R 964 Litronic weigh?

The Liebherr R 964 Litronic weighs 38.6 tons.

What are the transport dimensions of the Liebherr R 964 Litronic crawler excavator?

The Liebherr R 964 Litronic has a transport length of 11.3 meters, a transport width of 3.19 meters, and a transport height of 3.25 meters.

What are the undercarriage specifications of the Liebherr R 964 Litronic?

The Liebherr R 964 Litronic has a long undercarriage and a track width of 600 mm.

What are the excavation performance specifications of the Liebherr R 964 Litronic?

The Liebherr R 964 Litronic has a dredging depth of 7 meters, a maximum horizontal reach of 10.9 meters, and is equipped with a monobloc boom.

What is the tear-out force of the Liebherr R 964 Litronic?

The Liebherr R 964 Litronic has a tear-out force of 191 kN.

What are the specifications of the primary work tool bucket on the Liebherr R 964 Litronic?

The primary work tool bucket of the Liebherr R 964 Litronic has a capacity of 1.8 cubic meters and a width of 1.5 meters.

How much is a Liebherr R 964 Litronic Crawler excavator (2012u20132013) worth?

The residual value of the Liebherr R 964 Litronic depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
