R 956 Liebherr excavator specs & Dimensions (2016 - 2019)

Liebherr R 956 is a crawler excavator manufactured from 2016 to 2019. It has a weight of 54.05 tons and a track width of 600 mm. T…

Liebherr R 956 is a crawler excavator manufactured from 2016 to 2019. It has a weight of 54.05 tons and a track width of 600 mm. The transport dimensions are 12.25 meters in length, 2.9 meters in width, and 3.335 meters in height. The machine features a tear-out force of 218 kN, a dredging depth of 7.7 meters, and a maximum horizontal reach of 11.5 meters. The bucket width is 1.95 meters, with a capacity of 2.7 cubic meters.

Crawler Excavators Liebherr R 956

Visit Liebherr live at

Technical specs - R 956 Liebherr

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
54.05 t
Transport length
12.25 m
Transport width
2.9 m
Transport height
3.335 m
Bucket capacity
2.7 m³
Undercarriage
HD
Track width
600 mm
Boom
MB
Max. Reach horizontal
11.5 m
Dredging depth
7.7 m
Tear-out force
218 kN
Bucket width
1.95 m
Model series
R
Engine manuf.
Liebherr
Engine type
D 936 A 7
Engine power
240 kW
Displacement
11.946 l
Revolutions at max torque
1000 rpm
Max. torque
2280 Nm
No. of cylinders
6
Cylinder bore x stroke
130x150 mm
Emission level
IV

More technical details, like: bucket capacity min., bucket capacity max., dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Liebherr R 956 FAQ

When was the Liebherr R 956 manufactured?

The Liebherr R 956 was manufactured from 2016 to 2019.

How much does the Liebherr R 956 weigh?

The Liebherr R 956 weighs 54.05 tons.

What are the transport dimensions of the Liebherr R 956 crawler excavator?

The Liebherr R 956 crawler excavator has a transport length of 12.25 meters, a transport width of 2.9 meters, and a transport height of 3.34 meters.

What are the undercarriage specifications of the Liebherr R 956?

The Liebherr R 956 has a heavy duty undercarriage with a track width of 600 mm.

What are the excavation performance specifications of the Liebherr R 956?

The Liebherr R 956 has a dredging depth of 7.7 meters, a maximum horizontal reach of 11.5 meters, and is equipped with a monobloc boom.

What is the tear-out force of the Liebherr R 956, given that no power rating data is available?

The Liebherr R 956 has a tear-out force of 218 kN. No power rating data is provided for this model.

What are the bucket specifications of the Liebherr R 956 crawler excavator?

The Liebherr R 956 crawler excavator has a bucket capacity of 2.7 cubic meters and a bucket width of 1.95 meters.

How much is a Liebherr R 956 Crawler excavator (2016u20132019) worth?

The residual value of the Liebherr R 956 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
