952 Liebherr excavator specs & Dimensions (1983 - 1993)

Liebherr 952 is a crawler excavator manufactured from 1983 to 1993. It has a weight of 46.5 tons and a track width of 750 mm. The …

Liebherr 952 is a crawler excavator manufactured from 1983 to 1993. It has a weight of 46.5 tons and a track width of 750 mm. The transport dimensions are 5.785 meters in length, 3.55 meters in width, and 3.28 meters in height. The excavator features a tear-out force of 206 kN, a dredging depth of 8 meters, and a maximum horizontal reach of 12.3 meters. The bucket width is 1.83 meters, with a capacity of 3.4 cubic meters.

Crawler Excavators Liebherr 952

Visit Liebherr live at

Technical specs - 952 Liebherr

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
46.5 t
Transport length
5.785 m
Transport width
3.55 m
Transport height
3.28 m
Bucket capacity
3.4 m³
Track width
750 mm
Max. Reach horizontal
12.3 m
Dredging depth
8 m
Tear-out force
206 kN
Bucket width
1.83 m
Engine manuf.
Cummins
Engine type
LT10C225
Engine power
156 kW
Revolutions at max torque
2100 rpm
No. of cylinders
6

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, boom, model series, dimension lxwxh, displacement, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Liebherr 952 FAQ

When was the Liebherr 952 manufactured?

The Liebherr 952 was manufactured from 1983 to 1993.

How much does the Liebherr 952 weigh?

The Liebherr 952 weighs 46.5 tons.

What are the transport dimensions of the Liebherr 952 crawler excavator?

The Liebherr 952 crawler excavator has a transport length of 5.79 meters, a transport width of 3.55 meters, and a transport height of 3.28 meters.

What is the track width of the Liebherr 952's undercarriage?

The Liebherr 952 has a track width of 750 mm.

What are the dredging depth and maximum horizontal reach of the Liebherr 952 crawler excavator?

The Liebherr 952 crawler excavator has a dredging depth of 8 meters and a maximum horizontal reach of 12.3 meters.

What is the tear-out force of the Liebherr 952 crawler excavator?

The Liebherr 952 crawler excavator has a tear-out force of 206 kN.

What are the bucket specifications of the Liebherr 952 crawler excavator?

The Liebherr 952 crawler excavator has a bucket capacity of 3.4 cubic meters and a bucket width of 1.83 meters.

How much is a Liebherr 952 Crawler excavator (1983u20131993) worth?

The residual value of the Liebherr 952 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
