942 Liebherr excavator specs & Dimensions (1980 - 1990)

Liebherr 942 is a crawler excavator manufactured from 1980 to 1990. It has a weight of 31.7 tons and a track width of 750 mm. The …

Liebherr 942 is a crawler excavator manufactured from 1980 to 1990. It has a weight of 31.7 tons and a track width of 750 mm. The transport dimensions are 5.24 meters in length, 3.15 meters in width, and 3.12 meters in height. The dredging depth is 8.1 meters, and the maximum horizontal reach is 11.2 meters. The bucket width is 1.612 meters, with a bucket capacity of 2.5 cubic meters.

Crawler Excavators Liebherr 942

Visit Liebherr live at

Technical specs - 942 Liebherr

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
31.7 t
Transport length
5.24 m
Transport width
3.15 m
Transport height
3.12 m
Bucket capacity
2.5 m³
Track width
750 mm
Max. Reach horizontal
11.2 m
Dredging depth
8.1 m
Bucket width
1.612 m
Engine manuf.
Deutz
Engine type
BF6L913
Engine power
134 kW
Revolutions at max torque
2300 rpm
No. of cylinders
6

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, boom, tear-out force, model series, dimension lxwxh, displacement, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Liebherr 942 FAQ

When was the Liebherr 942 manufactured?

The Liebherr 942 was manufactured from 1980 to 1990.

How much does the Liebherr 942 weigh?

The Liebherr 942 weighs 31.7 tons.

What are the transport dimensions of the Liebherr 942 crawler excavator?

The Liebherr 942 crawler excavator has a transport length of 5.24 meters, a transport width of 3.15 meters, and a transport height of 3.12 meters.

What is the track width of the Liebherr 942's undercarriage?

The Liebherr 942 has a track width of 750 mm.

What is the excavation performance of the Liebherr 942 crawler excavator?

The Liebherr 942 crawler excavator has a dredging depth of 8.1 meters and a maximum horizontal reach of 11.2 meters.

What are the bucket specifications of the Liebherr 942 crawler excavator?

The Liebherr 942 has a bucket capacity of 2.5 cubic meters and a bucket width of 1.612 meters.
