KX080-4S Kubota excavator specs & Dimensions (2019 - 2026)

Kubota KX080-4S is a crawler excavator manufactured since 2019. It has a weight of 8.33 tons and a track width of 450 mm. The tran…

Kubota KX080-4S is a crawler excavator manufactured since 2019. It has a weight of 8.33 tons and a track width of 450 mm. The transport dimensions are 6.45 meters in length, 2.2 meters in width, and 2.54 meters in height. The machine features a tear-out force of 65 kN, a dredging depth of 4.6 meters, and a maximum horizontal reach of 7.17 meters. Special equipment includes air conditioning, a blade, and rubber tracks.

Crawler Excavators Kubota KX080-4S

Technical specs - KX080-4S Kubota

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
8.33 t
Transport length
6.45 m
Transport width
2.2 m
Transport height
2.54 m
Track width
450 mm
Max. Reach horizontal
7.17 m
Dredging depth
4.6 m
Tear-out force
65 kN
Model series
KX
Engine manuf.
Kubota
Engine type
V3307CR-TE4
Engine power
49.7 kW
Displacement
3.33 l
Emission level
Tier IV

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., undercarriage, boom, bucket width, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Kubota KX080-4S FAQ

When was the Kubota KX080-4S manufactured?

The Kubota KX080-4S was first produced in 2019.

How much does the Kubota KX080-4S weigh?

The Kubota KX080-4S weighs 8.33 tons.

What are the transport dimensions of the Kubota KX080-4S?

The Kubota KX080-4S has a transport length of 6.45 meters, a transport width of 2.2 meters, and a transport height of 2.54 meters.

What is the track width of the Kubota KX080-4S's undercarriage?

The Kubota KX080-4S has a track width of 450 mm.

What are the excavation performance specifications of the Kubota KX080-4S?

The Kubota KX080-4S has a dredging depth of 4.6 meters and a maximum horizontal reach of 7.17 meters.

What power ratings are available for the Kubota KX080-4S?

The source data does not provide power ratings for the Kubota KX080-4S. However, it has a tear-out force of 65 kN.

How much is a Kubota KX080-4S Crawler excavator (2019u20132025) worth?

The residual value of the Kubota KX080-4S depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
