PC88MR-10 Komatsu excavator specs & Dimensions (2015 - 2020)

Komatsu PC88MR-10 is a crawler excavator manufactured from 2015 to 2020. It has a weight of 8.72 tons and a track width of 450 mm.…

Komatsu PC88MR-10 is a crawler excavator manufactured from 2015 to 2020. It has a weight of 8.72 tons and a track width of 450 mm. The transport dimensions are 6.2 meters in length, 2.7 meters in width, and 2.3 meters in height. The bucket capacity is 0.235 cubic meters, and it is equipped with a blade.

Crawler Excavators Komatsu PC88MR-10
Crawler Excavators Komatsu PC88MR-10
Crawler Excavators Komatsu PC88MR-10
Crawler Excavators Komatsu PC88MR-10
Crawler Excavators Komatsu PC88MR-10
Crawler Excavators Komatsu PC88MR-10
Crawler Excavators Komatsu PC88MR-10
Crawler Excavators Komatsu PC88MR-10

Visit Komatsu live at

Technical specs - PC88MR-10 Komatsu

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
8.72 t
Transport length
6.2 m
Transport width
2.7 m
Transport height
2.3 m
Bucket capacity
0.235 m³
Track width
450 mm
Boom
MB
Max. Reach horizontal
7.345 m
Dredging depth
4.565 m
Model series
PC
Engine manuf.
Komatsu
Engine type
SAA4D95LE-6
Engine power
50.7 kW
Displacement
3.26 l
Revolutions at max torque
1950 rpm
No. of cylinders
4
Cylinder bore x stroke
95x115 mm
Emission level
III B

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, tear-out force, bucket width, dimension lxwxh, max. torque are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Komatsu PC88MR-10 FAQ

When was the Komatsu PC88MR-10 manufactured?

The Komatsu PC88MR-10 was manufactured from 2015 to 2020.

How much does the Komatsu PC88MR-10 weigh?

The Komatsu PC88MR-10 weighs 8.72 tons.

What are the transport dimensions of the Komatsu PC88MR-10?

The Komatsu PC88MR-10 has a transport length of 6.2 meters, a transport width of 2.7 meters, and a transport height of 2.3 meters.

What is the track width of the Komatsu PC88MR-10's undercarriage?

The Komatsu PC88MR-10 has a track width of 450 mm.

What are the excavation performance specifications of the Komatsu PC88MR-10?

The Komatsu PC88MR-10 has a dredging depth of 4.565 meters, a maximum horizontal reach of 7.345 meters, and features a monobloc boom.

What is the bucket capacity of the Komatsu PC88MR-10?

The Komatsu PC88MR-10 has a bucket capacity of 0.235 cubic meters.

How much is a Komatsu PC88MR-10 Crawler excavator (2015u20132020) worth?

The residual value of the Komatsu PC88MR-10 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
