PC240NLCD-8 Komatsu excavator specs & Dimensions (2012 - 2013)

Komatsu PC240NLCD-8 is a crawler excavator manufactured from 2012 to 2013, with a weight of 25.3 tons. It features a track width o…

Komatsu PC240NLCD-8 is a crawler excavator manufactured from 2012 to 2013, with a weight of 25.3 tons. It features a track width of 600 mm, a transport length of 9.9 meters, a transport width of 3.2 meters, and a transport height of 3.05 meters. The machine has a tear-out force of 160 kN and is equipped with air conditioning and an overload alert system.

Crawler Excavators Komatsu PC240NLCD-8

Visit Komatsu live at

Technical specs - PC240NLCD-8 Komatsu

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
25.3 t
Transport length
9.9 m
Transport width
3.2 m
Transport height
3.05 m
Bucket capacity
0.47 m³
Undercarriage
NLC
Track width
600 mm
Boom
MB
Max. Reach horizontal
10.97 m
Dredging depth
7.32 m
Tear-out force
160 kN
Model series
PC
Engine manuf.
Komatsu
Engine type
SAA6D107
Engine power
134 kW
Displacement
6.69 l
Revolutions at max torque
2000 rpm

More technical details, like: bucket capacity min., bucket capacity max., bucket width, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Komatsu PC240NLCD-8 FAQ

When was the Komatsu PC240NLCD-8 manufactured?

The Komatsu PC240NLCD-8 was manufactured from 2012 to 2013.

How much does the Komatsu PC240NLCD-8 weigh?

The Komatsu PC240NLCD-8 weighs 25.3 tons.

What are the transport dimensions of the Komatsu PC240NLCD-8?

The Komatsu PC240NLCD-8 has a transport length of 9.9 meters, a transport width of 3.2 meters, and a transport height of 3.05 meters.

What are the undercarriage specifications of the Komatsu PC240NLCD-8?

The Komatsu PC240NLCD-8 has a small undercarriage with a track width of 600 mm.

What are the excavation performance specifications of the Komatsu PC240NLCD-8?

The Komatsu PC240NLCD-8 has a dredging depth of 7.32 meters, a maximum horizontal reach of 10.97 meters, and features a monobloc boom.

What power ratings are available for the Komatsu PC240NLCD-8?

The Komatsu PC240NLCD-8 does not have power ratings listed in the provided data. However, it has a tear-out force of 160 kN.

What is the bucket capacity of the Komatsu PC240NLCD-8?

The Komatsu PC240NLCD-8 has a bucket capacity of 0.47 cubic meters.

How much is a Komatsu PC240NLCD-8 Crawler excavator (2012u20132013) worth?

The residual value of the Komatsu PC240NLCD-8 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
