SK 260 LC 10 Kobelco excavator specs & Dimensions (2015 - 2019)

Kobelco SK 260 LC 10 is a crawler excavator manufactured from 2015 to 2019. It has a weight of 26.2 tons and a track width of 600 …

Kobelco SK 260 LC 10 is a crawler excavator manufactured from 2015 to 2019. It has a weight of 26.2 tons and a track width of 600 mm. The transport dimensions are 10.22 meters in length, 3.19 meters in width, and 3.09 meters in height. The excavator features a tear-out force of 156 kN, a dredging depth of 7.68 meters, and a maximum horizontal reach of 10.98 meters. The bucket width is 1.34 meters with a capacity of 1.2 cubic meters. Special equipment includes air conditioning, a diesel particulate filter, an overload alert, and a hydraulic quick hitch.

Crawler Excavators Kobelco SK 260 LC 10
Crawler Excavators Kobelco SK 260 LC 10
Crawler Excavators Kobelco SK 260 LC 10
Crawler Excavators Kobelco SK 260 LC 10
Crawler Excavators Kobelco SK 260 LC 10
Crawler Excavators Kobelco SK 260 LC 10
Crawler Excavators Kobelco SK 260 LC 10
Crawler Excavators Kobelco SK 260 LC 10
Crawler Excavators Kobelco SK 260 LC 10
Crawler Excavators Kobelco SK 260 LC 10

Visit Kobelco live at

Technical specs - SK 260 LC 10 Kobelco

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
26.2 t
Transport length
10.22 m
Transport width
3.19 m
Transport height
3.09 m
Bucket capacity
1.2 m³
Undercarriage
LC
Track width
600 mm
Boom
MB
Max. Reach horizontal
10.98 m
Dredging depth
7.68 m
Tear-out force
156 kN
Bucket width
1.34 m
Engine manuf.
Hino
Engine type
J 05 EUN-KSSD
Engine power
138 kW
Displacement
5.123 l
Revolutions at max torque
1600 rpm
Max. torque
660 Nm
No. of cylinders
4
Cylinder bore x stroke
112x130 mm
Emission level
Tier 4 Final

More technical details, like: bucket capacity min., bucket capacity max., model series, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
Yes
Quick hitch mech.
No

Download datasheets (PDF)

Kobelco SK 260 LC 10 FAQ

When was the Kobelco SK 260 LC 10 manufactured?

The Kobelco SK 260 LC 10 was manufactured from 2015 to 2019.

How much does the Kobelco SK 260 LC 10 weigh?

The Kobelco SK 260 LC 10 weighs 26.2 tons.

What are the transport dimensions of the Kobelco SK 260 LC 10?

The Kobelco SK 260 LC 10 has a transport length of 10.22 meters, a transport width of 3.19 meters, and a transport height of 3.09 meters.

What are the undercarriage specifications of the Kobelco SK 260 LC 10?

The Kobelco SK 260 LC 10 has a long undercarriage with a track width of 600 mm.

What are the excavation performance specifications of the Kobelco SK 260 LC 10?

The Kobelco SK 260 LC 10 has a dredging depth of 7.68 meters, a maximum horizontal reach of 10.98 meters, and is equipped with a monobloc boom.

What is the tear-out force, the available power-related rating, of the Kobelco SK 260 LC 10?

The Kobelco SK 260 LC 10 has a tear-out force of 156 kN.

What are the bucket specifications of the Kobelco SK 260 LC 10 excavator?

The Kobelco SK 260 LC 10 has a bucket capacity of 1.2 cubic meters and a bucket width of 1.34 meters.

How much is a Kobelco SK 260 LC 10 Crawler excavator (2015u20132019) worth?

The residual value of the Kobelco SK 260 LC 10 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
