SK 210 LC 9 Kobelco excavator specs & Dimensions (2013 - 2015)

Kobelco SK 210 LC 9 is a Crawler Excavator manufactured from 2013 to 2015. It has a weight of 22.8 tons and a track width of 600 m…

Kobelco SK 210 LC 9 is a Crawler Excavator manufactured from 2013 to 2015. It has a weight of 22.8 tons and a track width of 600 mm. The transport dimensions are 12.64 meters in length, 2.99 meters in width, and 3.1 meters in height. The excavator features a tear-out force of 133 kN, a dredging depth of 12.01 meters, and a maximum horizontal reach of 15.82 meters. It is equipped with a bucket capacity of 0.45 cubic meters and includes special equipment such as air conditioning and a diesel particulate filter.

Crawler Excavators Kobelco SK 210 LC 9

Visit Kobelco live at

Technical specs - SK 210 LC 9 Kobelco

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
22.8 t
Transport length
12.64 m
Transport width
2.99 m
Transport height
3.1 m
Bucket capacity
0.45 m³
Undercarriage
LC
Track width
600 mm
Boom
MB
Max. Reach horizontal
15.82 m
Dredging depth
12.01 m
Tear-out force
133 kN
Engine manuf.
Hino
Engine type
J 05 E-TJ
Engine power
124 kW
Displacement
5.123 l
Revolutions at max torque
1600 rpm
Emission level
Tier 4 interim

More technical details, like: bucket capacity min., bucket capacity max., bucket width, model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Kobelco SK 210 LC 9 FAQ

When was the Kobelco SK 210 LC 9 manufactured?

The Kobelco SK 210 LC 9 was manufactured from 2013 to 2015.

How much does the Kobelco SK 210 LC 9 weigh?

The Kobelco SK 210 LC 9 weighs 22.8 tons.

What are the transport dimensions of the Kobelco SK 210 LC 9?

The Kobelco SK 210 LC 9 has a transport length of 12.64 meters, a transport width of 2.99 meters, and a transport height of 3.1 meters.

What are the undercarriage specifications of the Kobelco SK 210 LC 9?

The Kobelco SK 210 LC 9 has a long undercarriage with a track width of 600 mm.

What are the excavation performance specifications of the Kobelco SK 210 LC 9?

The Kobelco SK 210 LC 9 has a dredging depth of 12.01 meters, a maximum horizontal reach of 15.82 meters, and features a monobloc boom.

What are the power ratings of the Kobelco SK 210 LC 9?

The source data does not provide power ratings for the Kobelco SK 210 LC 9.

What is the bucket capacity of the Kobelco SK 210 LC 9?

The Kobelco SK 210 LC 9 has a bucket capacity of 0.45 cubic meters.

How much is a Kobelco SK 210 LC 9 Crawler excavator (2013u20132015) worth?

The residual value of the Kobelco SK 210 LC 9 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
