SK 210 LC 10 Kobelco excavator specs & Dimensions (2022 - 2026)

Kobelco SK 210 LC 10 is a crawler excavator manufactured since 2022. It has a weight of 23.7 tons and a track width of 800 mm. The…

Kobelco SK 210 LC 10 is a crawler excavator manufactured since 2022. It has a weight of 23.7 tons and a track width of 800 mm. The transport dimensions are 12.69 meters in length, 3.18 meters in width, and 3.12 meters in height. The excavator features a tear-out force of 229 kN, a dredging depth of 12.015 meters, and a maximum horizontal reach of 15.825 meters. The bucket width is 1.524 meters, with a bucket capacity ranging from 0.49 to 0.63 cubic meters.

Crawler Excavators Kobelco SK 210 LC 10

Visit Kobelco live at

Technical specs - SK 210 LC 10 Kobelco

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
23.7 t
Transport length
12.69 m
Transport width
3.18 m
Transport height
3.12 m
Bucket capacity min.
0.49 m³
Bucket capacity max.
0.63 m³
Undercarriage
LC
Track width
800 mm
Max. Reach horizontal
15.825 m
Dredging depth
12.015 m
Tear-out force
229 kN
Bucket width
1.524 m
Model series
SK
Engine manuf.
Hino
Engine type
J05E UM
Engine power
119 kW
Displacement
5.123 l
Revolutions at max torque
2000 rpm
Max. torque
640 Nm

More technical details, like: bucket capacity, boom, dimension lxwxh, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Kobelco SK 210 LC 10 FAQ

When was the Kobelco SK 210 LC 10 manufactured?

The Kobelco SK 210 LC 10 was first produced in 2022.

How much does the Kobelco SK 210 LC 10 weigh?

The Kobelco SK 210 LC 10 weighs 23.7 tons.

What are the transport dimensions of the Kobelco SK 210 LC 10?

The Kobelco SK 210 LC 10 has a transport length of 12.69 meters, a transport width of 3.18 meters, and a transport height of 3.12 meters.

What are the undercarriage specifications of the Kobelco SK 210 LC 10?

The Kobelco SK 210 LC 10 has a long undercarriage with a track width of 800 mm.

What are the excavation performance specifications of the Kobelco SK 210 LC 10?

The Kobelco SK 210 LC 10 has a dredging depth of 12.015 meters and a maximum horizontal reach of 15.825 meters.

What is the tear-out force of the Kobelco SK 210 LC 10, the available power-related specification?

The Kobelco SK 210 LC 10 has a tear-out force of 229 kN. No other power ratings are provided in the available data.

What are the specifications of the primary work tool bucket on the Kobelco SK 210 LC 10?

The Kobelco SK 210 LC 10 has a bucket with a maximum capacity of 0.63 mu00b3, a minimum capacity of 0.49 mu00b3, and a width of 1.524 meters.

How much is a Kobelco SK 210 LC 10 Crawler excavator (2022u20132025) worth?

The residual value of the Kobelco SK 210 LC 10 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
