SK 170 LC 10 Kobelco excavator specs & Dimensions (2021 - 2026)

Kobelco SK 170 LC 10 is a Crawler Excavator manufactured since 2021, with a weight of 17.6 tons. It features a track width of 600 …

Kobelco SK 170 LC 10 is a Crawler Excavator manufactured since 2021, with a weight of 17.6 tons. It features a track width of 600 mm, a transport length of 8.71 meters, a transport width of 2.78 meters, and a transport height of 9.77 meters. The excavator has a tear-out force of 231 kN, a dredging depth of 6.49 meters, and a maximum horizontal reach of 9.1 meters. The bucket capacity ranges from 0.46 m³ to 0.76 m³. Special equipment includes air conditioning, cabin adjustment, and an overload alert system.

Crawler Excavators Kobelco SK 170 LC 10

Visit Kobelco live at

Technical specs - SK 170 LC 10 Kobelco

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
17.6 t
Transport length
8.71 m
Transport width
2.78 m
Transport height
9.77 m
Bucket capacity min.
0.46 m³
Bucket capacity max.
0.76 m³
Track width
600 mm
Max. Reach horizontal
9.1 m
Dredging depth
6.49 m
Tear-out force
231 kN
Model series
SK
Engine manuf.
Hino
Engine type
J05EUM-KSST
Engine power
100 kW
Displacement
5.123 l
Revolutions at max torque
1600 rpm
Max. torque
370 Nm
No. of cylinders
4
Cylinder bore x stroke
112x130 mm
Emission level
Tier IV

More technical details, like: bucket capacity, undercarriage, boom, bucket width, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
Yes
Overload alert
Yes
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Kobelco SK 170 LC 10 FAQ

When was the Kobelco SK 170 LC 10 manufactured?

The Kobelco SK 170 LC 10 was first produced in 2021.

How much does the Kobelco SK 170 LC 10 weigh?

The Kobelco SK 170 LC 10 weighs 17.6 tons.

What are the transport dimensions of the Kobelco SK 170 LC 10?

The Kobelco SK 170 LC 10 has a transport length of 8.71 meters, a transport width of 2.78 meters, and a transport height of 9.77 meters.

What is the track width of the Kobelco SK 170 LC 10's undercarriage?

The Kobelco SK 170 LC 10 has a track width of 600 mm.

What are the excavation performance specifications of the Kobelco SK 170 LC 10?

The Kobelco SK 170 LC 10 has a dredging depth of 6.49 meters and a maximum horizontal reach of 9.1 meters.

What is the tear-out force of the Kobelco SK 170 LC 10?

The Kobelco SK 170 LC 10 has a tear-out force of 231 kN.

What are the bucket capacity specifications of the Kobelco SK 170 LC 10 excavator?

The Kobelco SK 170 LC 10 excavator has a bucket capacity ranging from 0.46 to 0.76 cubic meters.

How much is a Kobelco SK 170 LC 10 Crawler excavator (2021u20132025) worth?

The residual value of the Kobelco SK 170 LC 10 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
