Technical specs - JS220SC JCB
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 21.48 t
- Transport length
- 9.58 m
- Transport width
- 2.77 m
- Transport height
- 3.23 m
- Bucket capacity
- 1.25 m³
- Track width
- 600 mm
- Boom
- MB
- Max. Reach horizontal
- 9.14 m
- Dredging depth
- 6.16 m
- Tear-out force
- 138.2 kN
- Bucket width
- 1.5 m
- Model series
- JS
- Engine manuf.
- JCB
- Engine type
- EcoMax
- Engine power
- 129 kW
- Displacement
- 4.8 l
- No. of cylinders
- 4
- Emission level
- IV
More technical details, like: bucket capacity min., bucket capacity max., undercarriage, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.
Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket
Special equipment
- Diesel particulate filter
-
No
- Track adjustment
-
No
- Blade
-
No
- Cabin adjustment
-
No
- Overload alert
-
No
- Material Handling Excavator
-
No
- Aircondition
-
No
- Quick hitch hydr.
-
No
- Quick hitch mech.
-
No
Download datasheets (PDF)
