HX75S Hyundai excavator specs & Dimensions (2021 - 2026)

Hyundai HX75S is a crawler excavator manufactured since 2021, with a weight of 7.42 tons. It has a transport length of 6.08 meters…

Hyundai HX75S is a crawler excavator manufactured since 2021, with a weight of 7.42 tons. It has a transport length of 6.08 meters, a transport width of 2.26 meters, and a transport height of 2.69 meters. The dredging depth is 4.015 meters, and the maximum horizontal reach is 6.335 meters. The bucket capacity is 0.32 cubic meters.

Crawler Excavators Hyundai HX75S
Crawler Excavators Hyundai HX75S
Crawler Excavators Hyundai HX75S
Crawler Excavators Hyundai HX75S

Visit Hyundai live at

Technical specs - HX75S Hyundai

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
7.42 t
Transport length
6.08 m
Transport width
2.26 m
Transport height
2.69 m
Bucket capacity
0.32 m³
Max. Reach horizontal
6.335 m
Dredging depth
4.015 m
Engine manuf.
Yanmar
Engine type
4TNV98-Z
Engine power
33.11 kW

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, track width, boom, tear-out force, bucket width, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque...

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, track width, boom, tear-out force, bucket width, model series, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Hyundai HX75S FAQ

When was the Hyundai HX75S manufactured?

The Hyundai HX75S was first produced in 2021.

How much does the Hyundai HX75S weigh?

The Hyundai HX75S weighs 7.42 tons.

What are the transport dimensions of the Hyundai HX75S crawler excavator?

The Hyundai HX75S has a transport length of 6.08 meters, a transport width of 2.26 meters, and a transport height of 2.69 meters.

What are the excavation performance specifications of the Hyundai HX75S?

The Hyundai HX75S has a dredging depth of 4.015 meters and a maximum horizontal reach of 6.335 meters.

What is the bucket capacity of the Hyundai HX75S crawler excavator?

The Hyundai HX75S crawler excavator has a bucket capacity of 0.32 cubic meters.

How much is a Hyundai HX75S Crawler excavator (2021u20132025) worth?

The residual value of the Hyundai HX75S depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Hyundai HX75S overview

Engine

Comportable and safe operating space

In order to reduce the fatigue of the driver's performance, HX75S provides a comfortable operating environment for the pilot.


Hydraulic and electronic system

Load Sensing System

The maximum flow rate of the main pump is 158.4-17.6 lpm. The new load sensing system provides faster independent action with low fuel consumption.
