590CT Hymac excavator specs & Dimensions (1980 - 2026)

Hymac 590CT is a Crawler Excavator manufactured since 1980, with a weight of 16 tons. It features a track width of 900 mm, a trans…

Hymac 590CT is a Crawler Excavator manufactured since 1980, with a weight of 16 tons. It features a track width of 900 mm, a transport length of 8 meters, a transport width of 2 meters, and a transport height of 4 meters. The machine has a dredging depth of 6 meters and a maximum horizontal reach of 9 meters. The bucket width is 1 meter, with a maximum bucket capacity of 1 cubic meter. Special equipment includes a blade, cabin adjustment, diesel particulate filter, and material handling capabilities.

Crawler Excavators Hymac 590CT

Technical specs - 590CT Hymac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
16.05 t
Transport length
8.3 m
Transport width
2.5 m
Transport height
4.6 m
Bucket capacity min.
0.5 m³
Bucket capacity max.
1 m³
Track width
900 mm
Max. Reach horizontal
9.4 m
Dredging depth
6.3 m
Bucket width
1.93 m

More technical details, like: bucket capacity, undercarriage, boom, tear-out force, model series, engine manuf., engine type, engine power, dimension lxwxh, displacement, revolutions at max torque, max. torque...

More technical details, like: bucket capacity, undercarriage, boom, tear-out force, model series, engine manuf., engine type, engine power, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
No
Blade
Yes
Cabin adjustment
Yes
Overload alert
No
Material Handling Excavator
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Hymac 590CT FAQ

When was the Hymac 590CT manufactured?

The Hymac 590CT was first produced in 1980.

How much does the Hymac 590CT weigh?

The Hymac 590CT weighs 16.05 tons.

What are the transport dimensions of the Hymac 590CT crawler excavator?

The Hymac 590CT has a transport length of 8.3 meters, a transport width of 2.5 meters, and a transport height of 4.6 meters.

What is the track width of the Hymac 590CT's undercarriage?

The Hymac 590CT has a track width of 900 mm in its undercarriage.

What are the dredging depth and maximum horizontal reach of the Hymac 590CT crawler excavator?

The Hymac 590CT crawler excavator has a dredging depth of 6.3 meters and a maximum horizontal reach of 9.4 meters.

What are the specifications of the primary work tool on the Hymac 590CT?

The primary work tool of the Hymac 590CT has a maximum bucket capacity of 1 cubic meter and a bucket width of 1.93 meters.

How much is a Hymac 590CT Crawler excavator (1980u20132025) worth?

The residual value of the Hymac 590CT depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
