590C Hymac excavator specs & Dimensions (1980 - 2026)

Hymac 590C is a crawler excavator manufactured since 1980, with a weight of 16 tons. It features a track width of 900 mm, a transp…

Hymac 590C is a crawler excavator manufactured since 1980, with a weight of 16 tons. It features a track width of 900 mm, a transport length of 8 meters, a transport width of 2 meters, and a transport height of 4 meters. The machine has a dredging depth of 6 meters and a maximum horizontal reach of 9 meters. The bucket width is 1 meter. Special equipment includes a blade, cabin adjustment, diesel particulate filter, and material handling capabilities.

Crawler Excavators Hymac 590C

Technical specs - 590C Hymac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
16.05 t
Transport length
8.3 m
Transport width
2.5 m
Transport height
4.6 m
Bucket capacity
0.76 m³
Bucket capacity min.
0.76 m³
Track width
900 mm
Max. Reach horizontal
9.4 m
Dredging depth
6.3 m
Bucket width
1.93 m

More technical details, like: bucket capacity max., undercarriage, boom, tear-out force, model series, engine manuf., engine type, engine power, dimension lxwxh, displacement, revolutions at max torque, max. torque...

More technical details, like: bucket capacity max., undercarriage, boom, tear-out force, model series, engine manuf., engine type, engine power, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
No
Blade
Yes
Cabin adjustment
Yes
Overload alert
No
Material Handling Excavator
Yes
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Hymac 590C FAQ

When was the Hymac 590C manufactured?

The Hymac 590C was first produced in 1980.

How much does the Hymac 590C weigh?

The Hymac 590C weighs 16.05 tons.

What are the transport dimensions of the Hymac 590C crawler excavator?

The Hymac 590C crawler excavator has a transport length of 8.3 meters, a transport width of 2.5 meters, and a transport height of 4.6 meters.

What is the track width of the Hymac 590C crawler excavator?

The Hymac 590C crawler excavator has a track width of 900 mm.

What are the excavation performance specifications of the Hymac 590C?

The Hymac 590C has a dredging depth of 6.3 meters and a maximum horizontal reach of 9.4 meters.

What are the bucket specifications of the Hymac 590C crawler excavator?

The Hymac 590C has a bucket capacity of 0.76 cubic meters and a bucket width of 1.93 meters.

How much is a Hymac 590C Crawler excavator (1980u20132025) worth?

The residual value of the Hymac 590C depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
