Technical specs - HMK 390 NLC Hidromek
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 39.6 t
- Transport length
- 11.01 m
- Transport width
- 2.99 m
- Transport height
- 3.64 m
- Bucket capacity
- 2.2 m³
- Undercarriage
- NLC
- Track width
- 600 mm
- Boom
- MB
- Max. Reach horizontal
- 10.15 m
- Dredging depth
- 6.56 m
- Tear-out force
- 243.2 kN
- Bucket width
- 1.75 m
- Model series
- HMK
- Engine manuf.
- Isuzu
- Engine type
- AQ-6HK1X
- Engine power
- 210 kW
- Displacement
- 7.79 l
- Revolutions at max torque
- 1500 rpm
- Max. torque
- 1080 Nm
- No. of cylinders
- 6
- Cylinder bore x stroke
- 115x125 mm
- Emission level
- Tier 4 f/EU IV
More technical details, like: bucket capacity min., bucket capacity max., dimension lxwxh are available in the full technical specs.
Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket
Special equipment
- Diesel particulate filter
-
Yes
- Track adjustment
-
Yes
- Blade
-
No
- Cabin adjustment
-
Yes
- Overload alert
-
Yes
- Material Handling Excavator
-
Yes
- Aircondition
-
Yes
- Quick hitch hydr.
-
Yes
- Quick hitch mech.
-
Yes
Download datasheets (PDF)
Hidromek HMK 390 NLC FAQ
How much does the Hidromek HMK 390 NLC weigh?
What are the transport dimensions of the Hidromek HMK 390 NLC?
What are the undercarriage specifications of the Hidromek HMK 390 NLC?
What are the excavation performance specifications of the Hidromek HMK 390 NLC?
What power rating information is available for the Hidromek HMK 390 NLC?
What are the bucket specifications of the Hidromek HMK 390 NLC?
