HMK 310 LC LR Hidromek excavator specs & Dimensions (2019 - 2026)

Hidromek HMK 310 LC LR is a Crawler Excavator manufactured since 2021, with a weight of 34.5 tons. It features a track width of 80…

Hidromek HMK 310 LC LR is a Crawler Excavator manufactured since 2021, with a weight of 34.5 tons. It features a track width of 800 mm, a transport length of 14.8 meters, a transport width of 3.4 meters, and a transport height of 3.27 meters. The machine has a dredging depth of 14.25 meters and a maximum horizontal reach of 18.24 meters. It comes with a bucket width of 1.49 meters and a bucket capacity of 1.6 cubic meters. The excavator is equipped with a blade as special equipment.

Crawler Excavators Hidromek HMK 310 LC LR

Visit Hidromek live at

Technical specs - HMK 310 LC LR Hidromek

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
35 t
Transport length
14.8 m
Transport width
3.2 m
Transport height
3.27 m
Bucket capacity
0.6 m³
Undercarriage
LC
Track width
800 mm
Boom
MB
Max. Reach horizontal
18.24 m
Dredging depth
14.25 m
Tear-out force
103 kN
Bucket width
1.49 m
Model series
HMK
Engine manuf.
Isuzu
Engine type
AQ-6HK1X
Engine power
197 kW
Displacement
7.79 l
Revolutions at max torque
1900 rpm
Max. torque
1050/1500 Nm
No. of cylinders
6
Cylinder bore x stroke
115x125 mm
Emission level
V

More technical details, like: bucket capacity min., bucket capacity max., dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
Yes
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Hidromek HMK 310 LC LR FAQ

When was the Hidromek HMK 310 LC LR manufactured?

The Hidromek HMK 310 LC LR was first produced in 2019.

How much does the Hidromek HMK 310 LC LR weigh?

The Hidromek HMK 310 LC LR weighs 34.5 tons.

What are the transport dimensions of the Hidromek HMK 310 LC LR?

The transport dimensions of the Hidromek HMK 310 LC LR are 14.8 meters in length, 3.4 meters in width, and 3.27 meters in height.

What are the undercarriage specifications of the Hidromek HMK 310 LC LR?

The Hidromek HMK 310 LC LR has a long undercarriage with a track width of 800 mm.

What are the excavation performance specifications of the Hidromek HMK 310 LC LR?

The Hidromek HMK 310 LC LR has a dredging depth of 14.25 meters, a maximum horizontal reach of 18.24 meters, and features a monobloc boom.

What are the specifications of the primary work tool on the Hidromek HMK 310 LC LR?

The primary work tool of the Hidromek HMK 310 LC LR has a bucket capacity of 1.6 cubic meters and a bucket width of 1.49 meters.

How much is a Hidromek HMK 310 LC LR Crawler excavator (2019u20132025) worth?

The residual value of the Hidromek HMK 310 LC LR depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
