HMK 310 LC Hidromek excavator specs & Dimensions (2019 - 2021)

Hidromek HMK 310 LC is a Crawler Excavator manufactured from 2020 to 2022, with a weight of 32.1 t and a track width of 600 mm. It…

Hidromek HMK 310 LC is a Crawler Excavator manufactured from 2020 to 2022, with a weight of 32.1 t and a track width of 600 mm. It has a transport length of 10.88 m, a transport width of 3.2 m, and a transport height of 3.49 m. The excavator features a tear-out force of 208.88 kN, a dredging depth of 6.76 m, and a maximum horizontal reach of 10.15 m. The bucket width is 1.49 m with a capacity of 1.6 m³. Special equipment includes air conditioning, cabin adjustment, a diesel particulate filter, material handling capabilities, an overload alert, hydraulic and mechanical quick hitches, and track adjustment.

Crawler Excavators Hidromek HMK 310 LC
Crawler Excavators Hidromek HMK 310 LC
Crawler Excavators Hidromek HMK 310 LC
Crawler Excavators Hidromek HMK 310 LC
Crawler Excavators Hidromek HMK 310 LC
Crawler Excavators Hidromek HMK 310 LC
Crawler Excavators Hidromek HMK 310 LC
Crawler Excavators Hidromek HMK 310 LC
Crawler Excavators Hidromek HMK 310 LC
Crawler Excavators Hidromek HMK 310 LC

Visit Hidromek live at

Technical specs - HMK 310 LC Hidromek

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
32.1 t
Transport length
10.88 m
Transport width
3.2 m
Transport height
3.49 m
Bucket capacity
1.6 m³
Undercarriage
LC
Track width
600 mm
Boom
MB
Max. Reach horizontal
10.15 m
Dredging depth
6.76 m
Tear-out force
208.88 kN
Bucket width
1.49 m
Model series
HMK
Engine manuf.
Isuzu
Engine type
AQ-6HK1X
Engine power
161 kW
Displacement
7.79 l
Revolutions at max torque
1500 rpm
Max. torque
940 Nm
No. of cylinders
6
Cylinder bore x stroke
115x125 mm
Emission level
Tier 4/EU IV

More technical details, like: bucket capacity min., bucket capacity max., dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
Yes
Blade
No
Cabin adjustment
Yes
Overload alert
Yes
Material Handling Excavator
Yes
Aircondition
Yes
Quick hitch hydr.
Yes
Quick hitch mech.
Yes

Download datasheets (PDF)

Hidromek HMK 310 LC FAQ

When was the Hidromek HMK 310 LC manufactured?

The Hidromek HMK 310 LC was manufactured from 2019 to 2021.

How much does the Hidromek HMK 310 LC weigh?

The Hidromek HMK 310 LC weighs 32.1 tons.

What are the transport dimensions of the Hidromek HMK 310 LC?

The Hidromek HMK 310 LC has a transport length of 10.88 meters, a transport width of 3.2 meters, and a transport height of 3.49 meters.

What are the undercarriage specifications of the Hidromek HMK 310 LC?

The Hidromek HMK 310 LC has a long undercarriage and a track width of 600 mm.

What are the excavation performance specifications of the Hidromek HMK 310 LC?

The Hidromek HMK 310 LC has a dredging depth of 6.76 meters, a maximum horizontal reach of 10.15 meters, and features a monobloc boom.

What is the power rating of the Hidromek HMK 310 LC, and if not available, what related force specification is provided?

The source data does not provide a power rating for the Hidromek HMK 310 LC. However, it has a tear-out force of 208.88 kN.

What are the specifications of the primary work tool on the Hidromek HMK 310 LC?

The primary work tool of the Hidromek HMK 310 LC has a bucket capacity of 1.6 cubic meters and a bucket width of 1.49 meters.

How much is a Hidromek HMK 310 LC Crawler excavator (2019u20132021) worth?

The residual value of the Hidromek HMK 310 LC depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
