65 NX Gehlmax-IHI excavator specs & Dimensions (2008 - 2012)

Gehlmax-IHI 65 NX is a crawler excavator manufactured from 2008 to 2012. It has a weight of 6.52 tons, a track width of 2100 mm, a…

Gehlmax-IHI 65 NX is a crawler excavator manufactured from 2008 to 2012. It has a weight of 6.52 tons, a track width of 2100 mm, a transport length of 5.93 meters, a transport width of 2.1 meters, and a transport height of 2.6 meters. The excavator features a tear-out force of 43 kN and a bucket width of 0.685 meters.

Crawler Excavators Gehlmax-IHI 65 NX

Technical specs - 65 NX Gehlmax-IHI

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
6.52 t
Transport length
5.93 m
Transport width
2.1 m
Transport height
2.6 m
Bucket capacity
0.2 m³
Track width
2100 mm
Boom
MB
Max. Reach horizontal
6.28 m
Dredging depth
4.215 m
Tear-out force
43 kN
Bucket width
0.685 m
Model series
NX
Engine manuf.
Yanmar
Engine type
4TNV98
Engine power
41 kW
Displacement
3.3 l
Revolutions at max torque
2400 rpm

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Gehlmax-IHI 65 NX FAQ

When was the Gehlmax-IHI 65 NX manufactured?

The Gehlmax-IHI 65 NX was manufactured from 2008 to 2012.

How much does the Gehlmax-IHI 65 NX weigh?

The Gehlmax-IHI 65 NX weighs 6.52 tons.

What are the transport dimensions of the Gehlmax-IHI 65 NX crawler excavator?

The Gehlmax-IHI 65 NX crawler excavator has a transport length of 5.93 meters, a transport width of 2.1 meters, and a transport height of 2.6 meters.

What is the track width of the Gehlmax-IHI 65 NX's undercarriage?

The Gehlmax-IHI 65 NX has a track width of 2100 mm.

What are the excavation performance specifications of the Gehlmax-IHI 65 NX?

The Gehlmax-IHI 65 NX has a dredging depth of 4.215 meters, a maximum horizontal reach of 6.28 meters, and features a Monobloc boom.

What power rating information is available for the Gehlmax-IHI 65 NX?

There is no power rating information available for the Gehlmax-IHI 65 NX in the provided data.

What are the specifications of the primary work tool bucket on the Gehlmax-IHI 65 NX?

The primary work tool bucket of the Gehlmax-IHI 65 NX has a capacity of 0.2 cubic meters and a width of 0.685 meters.
