DX380LC-5 Doosan excavator specs & Dimensions (2017 - 2021)

Doosan DX380LC-5 is a Crawler Excavator manufactured from 2017 to 2021, with a weight of 40 tons. It features a track width of 600…

Doosan DX380LC-5 is a Crawler Excavator manufactured from 2017 to 2021, with a weight of 40 tons. It features a track width of 600 mm, a transport length of 11 meters, a transport width of 3 meters, and a transport height of 3 meters. The dredging depth is 7.46 meters. Special equipment includes air conditioning and an overload alert system.

Crawler Excavators Doosan DX380LC-5

Technical specs - DX380LC-5 Doosan

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
40 t
Transport length
11 m
Transport width
3 m
Transport height
3 m
Bucket capacity
1.61 m³
Undercarriage
LC
Track width
600 mm
Boom
MB
Max. Reach horizontal
10.97 m
Dredging depth
7.46 m
Tear-out force
243.1 kN
Bucket width
1.55 m
Model series
DX
Engine manuf.
Scania
Engine type
DC 09
Engine power
233 kW
Displacement
9.3 l
Revolutions at max torque
1300 rpm
Max. torque
1324 Nm
No. of cylinders
5
Cylinder bore x stroke
130x140 mm
Emission level
IV

More technical details, like: bucket capacity min., bucket capacity max., dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Doosan DX380LC-5 FAQ

When was the Doosan DX380LC-5 manufactured?

The Doosan DX380LC-5 was manufactured from 2017 to 2021.

How much does the Doosan DX380LC-5 weigh?

The Doosan DX380LC-5 weighs 40 tons.

What are the transport dimensions of the Doosan DX380LC-5?

The Doosan DX380LC-5 has a transport length of 11 meters, a transport width of 3 meters, and a transport height of 3 meters.

What are the undercarriage specifications of the Doosan DX380LC-5?

The Doosan DX380LC-5 has a long undercarriage and a track width of 600 mm.

What are the excavation performance specifications of the Doosan DX380LC-5?

The Doosan DX380LC-5 has a dredging depth of 7.46 meters, a maximum horizontal reach of 10.97 meters, and features a monobloc boom.

What is the tear-out force of the Doosan DX380LC-5?

The Doosan DX380LC-5 has a tear-out force of 243.1 kN.

What are the specifications of the primary work tool bucket on the Doosan DX380LC-5?

The primary work tool bucket of the Doosan DX380LC-5 has a capacity of 1.61 cubic meters and a width of 1.55 meters.

How much is a Doosan DX380LC-5 Crawler excavator (2017u20132021) worth?

The residual value of the Doosan DX380LC-5 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
