DX340LCA Doosan excavator specs & Dimensions (2019 - 2021)

Doosan DX340LCA is a crawler excavator manufactured from 2019 to 2021, with a weight of 34 tons. It features a track width of 600 …

Doosan DX340LCA is a crawler excavator manufactured from 2019 to 2021, with a weight of 34 tons. It features a track width of 600 mm, a transport length of 11 meters, a transport width of 3 meters, and a transport height of 3 meters. The machine has a tear-out force of 203 kN and comes equipped with air conditioning.

Crawler Excavators Doosan DX340LCA

Technical specs - DX340LCA Doosan

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
34 t
Transport length
11 m
Transport width
3 m
Transport height
3 m
Bucket capacity
1.49 m³
Track width
600 mm
Max. Reach horizontal
10.98 m
Dredging depth
7.53 m
Tear-out force
203 kN
Bucket width
1.46 m
Model series
DX
Engine manuf.
Doosan
Engine type
DE12TIS
Engine power
195 kW
Displacement
11.1 l
Revolutions at max torque
1400 rpm
Max. torque
1118 Nm
No. of cylinders
6
Cylinder bore x stroke
123 x 155 mm

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, boom, dimension lxwxh, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Doosan DX340LCA FAQ

When was the Doosan DX340LCA manufactured?

The Doosan DX340LCA was manufactured from 2019 to 2021.

How much does the Doosan DX340LCA weigh?

The Doosan DX340LCA weighs 34 tons.

What are the transport dimensions of the Doosan DX340LCA crawler excavator?

The Doosan DX340LCA has a transport length of 11 meters, a transport width of 3 meters, and a transport height of 3 meters.

What is the track width of the Doosan DX340LCA crawler excavator?

The Doosan DX340LCA crawler excavator has a track width of 600 mm.

What are the excavation performance specifications of the Doosan DX340LCA?

The Doosan DX340LCA has a dredging depth of 7.53 meters and a maximum horizontal reach of 10.98 meters.

What is the power rating of the Doosan DX340LCA?

Power rating data for the Doosan DX340LCA is not available in the provided information.

What are the specifications of the primary work tool on the Doosan DX340LCA?

The primary work tool of the Doosan DX340LCA has a bucket capacity of 1.49 cubic meters and a bucket width of 1.46 meters.

How much is a Doosan DX340LCA Crawler excavator (2019u20132021) worth?

The residual value of the Doosan DX340LCA depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
