    Case CX80C MSR excavator specs (2013 - 2018)

    Rate this machine now!

    The CX 80 C-MSR crawler excavator model is manufactured by case. Find and download detailed specs and data sheets for this machine... Read more

    The CX 80 C-MSR crawler excavator model is manufactured by case. Find and download detailed specs and data sheets for this machine here.

    Equipped with a powerful Isuzu engine, this CX 80 C-MSR 8.69t machine can provide 40kW or 53 horse power for the crawler excavator. The CX 80 C-MSR is categorised in the smallest machine segment in the crawler excavators category. The CX 80 C-MSR’s size is 2.32m x 6.68m x 2.86m.

    The case CX 80 C-MSR has been equipped and sold with Blade, Quick hitch hydr. And Aircondition. Cabin adjustment, Material Handling Excavator and Track adaption are not provided on this model as of 2017. There are more detailed specifications and machine descriptions available in the original case CX 80 C-MSR specs data sheet. Download a free data sheet in English from LECTURA Specs.

    The production is still going in 2017, where this CX 80 C-MSR is available at a new list price between €119000 and €151000. For more detailed information about pricing and current residual values, check out the LECTURA Valuation system.

    At present, 46 other crawler excavators, which range from 7.9t up to 72t are produced by case. Of these, CX 235 C SR LC Mono, CX 160 D and also CX 145 C SR Blade are the most frequently visited on LECTURA Specs. Having been in production from 2013 to 2017, the CX 80 C-MSR crawler excavator ranks in the LECTURA index at #60. Want more detailed specifications? Download the latest case CX 80 C-MSR specs data sheet on LECTURA Specs today!

    Technical specs - CX80C MSR Case


    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur.Contact our team with any change suggestion.

    • Weight 8.69 t
    • Transport length 6.68 m
    • Transport width 2.32 m
    • Transport height 2.76 m
    • Bucket capacity 0.28 m³
    • Track width 450 mm
    • Max. Reach horizontal 6.41 m
    • Dredging depth 4.13 m
    • Tear-out force 56.9 kN
    • Bucket width 0.8 m
    • Engine manuf. Isuzu
    • Engine type AP-4LE2X
    • Engine power 41.2 kW
    • Displacement 2.179 l
    • Revolutions at max torque 1800 rpm
    • Max. torque 193 Nm
    • Emission level Tier 4 Final / Stage IIIB

    More technical details, like: bucket capacity min., bucket capacity max., undercarriage, boom, dimension lxwxh, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

    Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

    Special equipment

    • Diesel particulate filter
    • Track adjustment
    • Blade
    • Cabin adjustment
    • Overload alert
    • Material Handling Excavator
    • Aircondition
    • Quick hitch hydr.
    • Quick hitch mech.
