CX490C Case excavator specs & Dimensions (2021 - 2026)

Case CX490C is a crawler excavator manufactured since 2021, with a weight of 48.7 tons. It features a track width of 600 mm, a tra…

Case CX490C is a crawler excavator manufactured since 2021, with a weight of 48.7 tons. It features a track width of 600 mm, a transport length of 12.1 meters, a transport width of 3.35 meters, and a transport height of 3.28 meters. The machine has a tear-out force of 266 kN, a dredging depth of 6.89 meters, a maximum horizontal reach of 11 meters, and a bucket capacity of 2.4 cubic meters.

Crawler Excavators Case CX490C

Technical specs - CX490C Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
48.7 t
Transport length
12.1 m
Transport width
3.35 m
Transport height
3.28 m
Bucket capacity
2.4 m³
Track width
600 mm
Max. Reach horizontal
11 m
Dredging depth
6.89 m
Tear-out force
266 kN
Model series
C
Engine manuf.
Isuzu
Engine type
GH-6UZ1X
Engine power
245 kW
Displacement
9.84 l
Revolutions at max torque
1500 rpm
Max. torque
1363 Nm
No. of cylinders
6
Cylinder bore x stroke
120x145 mm
Emission level
Tier III

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, boom, bucket width, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Case CX490C FAQ

When was the Case CX490C manufactured?

The Case CX490C was first produced in 2021.

How much does the Case CX490C weigh?

The Case CX490C weighs 48.7 tons.

What are the transport dimensions of the Case CX490C crawler excavator?

The Case CX490C has a transport length of 12.1 meters, a transport width of 3.35 meters, and a transport height of 3.28 meters.

What is the track width of the Case CX490C's undercarriage?

The Case CX490C has a track width of 600 mm.

What is the excavation performance of the Case CX490C crawler excavator?

The Case CX490C has a dredging depth of 6.89 meters and a maximum horizontal reach of 11 meters.

What is the tear-out force of the Case CX490C?

The Case CX490C has a tear-out force of 266 kN.

What is the bucket capacity of the Case CX490C crawler excavator?

The Case CX490C crawler excavator has a bucket capacity of 2.4 cubic meters.

How much is a Case CX490C Crawler excavator (2021u20132025) worth?

The residual value of the Case CX490C depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
