CX470D Case excavator specs & Dimensions (2017 - 2017)

Case CX470D is a Crawler Excavator manufactured from 2017 to 2017, with a weight of 49.3 tons. It features a track width of 600 mm…

Case CX470D is a Crawler Excavator manufactured from 2017 to 2017, with a weight of 49.3 tons. It features a track width of 600 mm, a transport length of 12 meters, a transport width of 3.35 meters, and a transport height of 4.3 meters. The excavator has a tear-out force of 229 kN, a dredging depth of 7.55 meters, and a maximum horizontal reach of 12 meters. The bucket width is 2 meters, and the bucket capacity is 2.1 cubic meters. Special equipment includes air conditioning, a diesel particulate filter, and track adjustment.

Crawler Excavators Case CX470D

Technical specs - CX470D Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
49.3 t
Transport length
12 m
Transport width
3.35 m
Transport height
4.3 m
Bucket capacity
2.1 m³
Undercarriage
LCV
Track width
600 mm
Boom
MB
Max. Reach horizontal
12 m
Dredging depth
7.55 m
Tear-out force
229 kN
Bucket width
2 m
Model series
D
Engine manuf.
Isuzu
Engine type
AL 6 UZ 1 X
Engine power
270 kW
Displacement
9.8 l
Revolutions at max torque
2000 rpm

More technical details, like: bucket capacity min., bucket capacity max., dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
Yes
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Case CX470D FAQ

When was the Case CX470D manufactured?

The Case CX470D was manufactured in 2017.

How much does the Case CX470D weigh?

The Case CX470D weighs 49.3 tons.

What are the transport dimensions of the Case CX470D crawler excavator?

The Case CX470D has a transport length of 12 meters, a transport width of 3.35 meters, and a transport height of 4.3 meters.

What are the undercarriage specifications of the Case CX470D crawler excavator?

The Case CX470D crawler excavator has a long undercarriage that is hydraulically extendable and features a track width of 600 mm.

What are the excavation performance specifications of the Case CX470D crawler excavator?

The Case CX470D has a dredging depth of 7.55 meters, a maximum horizontal reach of 12 meters, and is equipped with a Monobloc boom.

What is the tear-out force of the Case CX470D?

The Case CX470D has a tear-out force of 229 kN.

What are the bucket specifications of the Case CX470D excavator?

The Case CX470D excavator has a bucket capacity of 2.1 cubic meters and a bucket width of 2 meters.
