CX370C Case excavator specs & Dimensions (2021 - 2026)

Case CX370C is a crawler excavator manufactured since 2021. It has a weight of 36.2 tons and a track width of 600 mm. The transpor…

Case CX370C is a crawler excavator manufactured since 2021. It has a weight of 36.2 tons and a track width of 600 mm. The transport dimensions are 11.35 meters in length, 3.2 meters in width, and 3.14 meters in height. The machine features a tear-out force of 252 kN, a dredging depth of 6.3 meters, and a maximum horizontal reach of 9.99 meters. The bucket capacity is 1.6 cubic meters.

Crawler Excavators Case CX370C

Technical specs - CX370C Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
36.2 t
Transport length
11.35 m
Transport width
3.2 m
Transport height
3.14 m
Bucket capacity
1.6 m³
Track width
600 mm
Max. Reach horizontal
9.99 m
Dredging depth
6.3 m
Tear-out force
252 kN
Model series
C
Engine manuf.
Isuzu
Engine type
GH-6HK1X
Engine power
200 kW
Displacement
7.79 l
Revolutions at max torque
1500 rpm
Max. torque
1020 Nm
No. of cylinders
6
Cylinder bore x stroke
115x125 mm

More technical details, like: bucket capacity min., bucket capacity max., undercarriage, boom, bucket width, dimension lxwxh, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Case CX370C FAQ

When was the Case CX370C manufactured?

The Case CX370C was first produced in 2021.

How much does the Case CX370C weigh?

The Case CX370C weighs 36.2 tons.

What are the transport dimensions of the Case CX370C crawler excavator?

The Case CX370C has a transport length of 11.35 meters, a transport width of 3.2 meters, and a transport height of 3.14 meters.

What is the track width of the Case CX370C crawler excavator?

The Case CX370C crawler excavator has a track width of 600 mm.

What are the excavation performance specifications of the Case CX370C?

The Case CX370C has a dredging depth of 6.3 meters and a maximum horizontal reach of 9.99 meters.

What is the power rating of the Case CX370C?

The source data does not provide power rating information for the Case CX370C.

What is the bucket capacity of the Case CX370C excavator?

The Case CX370C excavator has a bucket capacity of 1.6 cubic meters.

How much is a Case CX370C Crawler excavator (2021u20132025) worth?

The residual value of the Case CX370C depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
