Case CX145D SR excavator specs (2021 - 2025)

Name: Case CX145D SR Crawler Excavators
Brand: Case

Case CX145D SR is a crawler excavator manufactured since 2021. It has a weight of 15.8 tons and a track width of 600 mm. The trans…

Case CX145D SR is a crawler excavator manufactured since 2021. It has a weight of 15.8 tons and a track width of 600 mm. The transport dimensions are 7.99 meters in length, 2.59 meters in width, and 2.92 meters in height. The machine features a tear-out force of 90 kN, a dredging depth of 5.31 meters, and a maximum horizontal reach of 8.28 meters. Special equipment includes air conditioning, a blade, and an overload alert system.

CX145D SR

Years of manufacture: 2021—2025

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events & News

Technical specs - CX145D SR Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 15.8 t

Transport length: 7.99 m

Transport width: 2.59 m

Transport height: 2.92 m

Track width: 600 mm

Boom: VA

Max. Reach horizontal: 8.28 m

Dredging depth: 5.31 m

Tear-out force: 90 kN

Model series: D

Engine manuf.: Isuzu

Engine type: AR-4JJ1X

Engine power: 76.4 kW

Displacement: 2.99 l

Revolutions at max torque: 1800 rpm

Max. torque: 349 Nm

No. of cylinders: 4

Cylinder bore x stroke: 95.4x104.9 mm

Emission level: EU V

More technical details, like: bucket capacity, bucket capacity min., bucket capacity max., undercarriage, bucket width, dimension lxwxh are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter: No
Track adjustment: No
Blade: Yes
Cabin adjustment: No
Overload alert: Yes
Material Handling Excavator: No
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: No
