CX 330 Case excavator specs & Dimensions (2001 - 2007)

Case CX 330 is a crawler excavator manufactured from 2001 to 2007. It has a weight of 33.8 tons and a track width of 600 mm. The t…

Case CX 330 is a crawler excavator manufactured from 2001 to 2007. It has a weight of 33.8 tons and a track width of 600 mm. The transport dimensions are 11.05 meters in length, 3.2 meters in width, and 3.29 meters in height. The machine provides a tear-out force of 153 kN and a maximum horizontal reach of 11 meters. It is equipped with air conditioning and an overload alert system.

Crawler Excavators Case CX 330

Technical specs - CX 330 Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
33.8 t
Transport length
11.05 m
Transport width
3.2 m
Transport height
3.29 m
Bucket capacity
1.8 m³
Undercarriage
NLC
Track width
600 mm
Boom
MB
Max. Reach horizontal
11 m
Dredging depth
8.14 m
Tear-out force
153 kN
Bucket width
1.5 m
Engine manuf.
Isuzu
Engine type
AA 6 HKIXQB
Engine power
202 kW
Displacement
7.79 l
Revolutions at max torque
2000 rpm

More technical details, like: bucket capacity min., bucket capacity max., model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
Yes
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Case CX 330 FAQ

When was the Case CX 330 manufactured?

The Case CX 330 was manufactured from 2001 to 2007.

How much does the Case CX 330 weigh?

The Case CX 330 weighs 33.8 tons.

What are the transport dimensions of the Case CX 330 crawler excavator?

The Case CX 330 has a transport length of 11.05 meters, a transport width of 3.2 meters, and a transport height of 3.29 meters.

What are the undercarriage specifications of the Case CX 330 crawler excavator?

The Case CX 330 crawler excavator has a small undercarriage with a track width of 600 mm.

What are the excavation performance specifications of the Case CX 330?

The Case CX 330 has a dredging depth of 8.14 meters, a maximum horizontal reach of 11 meters, and is equipped with a monobloc boom.

What is the power rating of the Case CX 330?

The power rating of the Case CX 330 is not provided in the available data.

What are the bucket specifications of the Case CX 330 excavator?

The Case CX 330 excavator has a bucket capacity of 1.8 cubic meters and a bucket width of 1.5 meters.

How much is a Case CX 330 Crawler excavator (2001u20132007) worth?

The residual value of the Case CX 330 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
