170C Case excavator specs & Dimensions (1987 - 2015)

Case 170C is a Crawler Excavator manufactured from 1987 to 2015. It has a weight of 32.84 tons and a track width of 850 mm. The tr…

Case 170C is a Crawler Excavator manufactured from 1987 to 2015. It has a weight of 32.84 tons and a track width of 850 mm. The transport dimensions are 11.04 meters in length, 3.45 meters in width, and 3.28 meters in height. The excavator features a tear-out force of 180 kN, a dredging depth of 7.65 meters, and a maximum horizontal reach of 11.15 meters. The bucket width is 1.22 meters, with a capacity ranging from 0.76 m³ to 1.43 m³.

Crawler Excavators Case 170C

Technical specs - 170C Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
32.84 t
Transport length
11.04 m
Transport width
3.45 m
Transport height
3.28 m
Bucket capacity
1.43 m³
Bucket capacity min.
0.76 m³
Bucket capacity max.
1.43 m³
Track width
850 mm
Max. Reach horizontal
11.15 m
Dredging depth
7.65 m
Tear-out force
180 kN
Bucket width
1.22 m
Model series
C
Engine manuf.
Deutz
Engine type
BF6L513R
Engine power
178 kW
Displacement
9.5 l
Revolutions at max torque
1500 rpm
Max. torque
905 Nm
No. of cylinders
6
Cylinder bore x stroke
130x125 mm

More technical details, like: undercarriage, boom, dimension lxwxh, emission level are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
No
Track adjustment
No
Blade
No
Cabin adjustment
No
Overload alert
No
Material Handling Excavator
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Case 170C FAQ

When was the Case 170C manufactured?

The Case 170C was manufactured from 1987 to 2015.

How much does the Case 170C weigh?

The Case 170C weighs 32.84 tons.

What are the transport dimensions of the Case 170C crawler excavator?

The Case 170C crawler excavator has a transport length of 11.04 meters, a transport width of 3.45 meters, and a transport height of 3.28 meters.

What is the track width of the Case 170C crawler excavator?

The Case 170C crawler excavator has a track width of 850 mm.

What are the excavation performance specifications of the Case 170C?

The Case 170C has a dredging depth of 7.65 meters and a maximum horizontal reach of 11.15 meters.

What is the tear-out force of the Case 170C crawler excavator?

The Case 170C crawler excavator has a tear-out force of 180 kN.

What are the bucket specifications of the Case 170C crawler excavator?

The Case 170C has a bucket capacity ranging from 0.76 to 1.43 cubic meters, with a bucket width of 1.22 meters.

How much is a Case 170C Crawler excavator (1987u20132015) worth?

The residual value of the Case 170C depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Case 170C overview

Engine

Case 1080B

With 44,070 pounds (20 031 kg) of operating weight, a choice of fuel-saving engines and high-performance hydraulics, you have built-in efficiency that can result in increased earnings for you.


Largest of the Delta Series

The Case 220B weighs in at approximately 95,460 pounds (43 270 kg) to make it a top contender in the 45-ton class. Because of its power, rugged design and capacity, it is especially suited for work in heavy rock, shale, coral, caliche and mass excavations.


Super performance

Super performance is founded upon the rugged strength of the Delta Series undercarriage—built to take the toughest conditions in stride. It continues with ready availability through minimum maintenance—you increase uptime and productivity on every site.


Hydraulic and electronic system

Constant flow, variable pressure hydraulics

offer smooth, independent or simultaneous control of all work functions as well as a fast hoist feature. The system also provides always-available auxiliary hydraulics. The 360° swing system has positive operator control with a disc brake for sure lock when swinging or transporting.


The variable-flow hydraulic system

The variable-flow hydraulic system includes a multi-body, four-section pump for simultaneous and independent command of boom, crowd, bucket, swing and travel functions. As with all Delta Series excavators, a heavy-lift feature is standard. Extra crowd power is automatically delivered when you need it. At the bucket, 53,760 pounds (239 136 N) of breakout force crack-out the most stubborn materials.


Always available auxiliary hydraulics

Always available auxiliary hydraulics are a feature of the 1085B's summarized hydraulics system. In addition to the independent or simultaneous operation of swing, crowd, lift and tool functions, two auxiliary spools are available for hydraulically-driven attachments.


Upper Structure

Maintenance-free Rollers and Idlers

in the crawler-tractor undercarriage as well as remote lube systems for boom, stick and swing gear simplify daily maintenance and help you achieve consistent high performance.


Cab

Operator efficiency

is increased and fatigue minimized by a cab that offers clear visibility of the work area, as well as a fully adjustable seat and conveniently located low-effort controls. It all adds up to comfort and convenience that can help to make long days seem shorter.
