340 LC Atlas excavator specs & Dimensions (2021 - 2026)

Atlas 340 LC is a Crawler Excavator manufactured since 2021, with a weight of 35.5 t and a track width of 600 mm. It has a transpo…

Atlas 340 LC is a Crawler Excavator manufactured since 2021, with a weight of 35.5 t and a track width of 600 mm. It has a transport length of 10.19 m, a transport width of 3.2 m, and a transport height of 3.45 m. The machine features a tear-out force of 134 kN, a dredging depth of 7.77 m, and a maximum horizontal reach of 10.73 m. The bucket capacity is 1.65 m³. Special equipment includes air conditioning, cabin adjustment, a diesel particulate filter, and an overload alert system.

Crawler Excavators Atlas 340 LC
Crawler Excavators Atlas 340 LC
Crawler Excavators Atlas 340 LC
Crawler Excavators Atlas 340 LC
Crawler Excavators Atlas 340 LC
Crawler Excavators Atlas 340 LC
Crawler Excavators Atlas 340 LC
Crawler Excavators Atlas 340 LC
Crawler Excavators Atlas 340 LC
Crawler Excavators Atlas 340 LC

Visit Atlas live at

Technical specs - 340 LC Atlas

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
35.5 t
Transport length
10.19 m
Transport width
3.2 m
Transport height
3.45 m
Bucket capacity
1.65 m³
Undercarriage
LC
Track width
600 mm
Boom
VA
Max. Reach horizontal
10.73 m
Dredging depth
7.77 m
Tear-out force
134 kN
Engine manuf.
Deutz
Engine type
TCD6.1
Engine power
180 kW
Displacement
6.1 l
Revolutions at max torque
1800 rpm
No. of cylinders
6
Emission level
V

More technical details, like: bucket capacity min., bucket capacity max., bucket width, model series, dimension lxwxh, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model incl. ROPS cabin, traction drive, standard boom and standard bucket

Special equipment

Diesel particulate filter
Yes
Track adjustment
No
Blade
No
Cabin adjustment
Yes
Overload alert
Yes
Material Handling Excavator
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Atlas 340 LC FAQ

When was the Atlas 340 LC manufactured?

The Atlas 340 LC was first produced in 2021.

How much does the Atlas 340 LC weigh?

The Atlas 340 LC weighs 35.5 tons.

What are the transport dimensions of the Atlas 340 LC?

The Atlas 340 LC has a transport length of 10.19 meters, a transport width of 3.2 meters, and a transport height of 3.45 meters.

What are the undercarriage specifications of the Atlas 340 LC?

The Atlas 340 LC has a long undercarriage with a track width of 600 mm.

What are the excavation performance specifications of the Atlas 340 LC?

The Atlas 340 LC has a dredging depth of 7.77 meters, a maximum horizontal reach of 10.73 meters, and features an adjustable boom.

What is the tear-out force of the Atlas 340 LC crawler excavator?

The Atlas 340 LC crawler excavator has a tear-out force of 134 kN.

What is the bucket capacity of the Atlas 340 LC crawler excavator?

The Atlas 340 LC crawler excavator has a bucket capacity of 1.65 cubic meters.

How much is a Atlas 340 LC Crawler excavator (2021u20132025) worth?

The residual value of the Atlas 340 LC depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
