TF 35.7 - 100 EE Merlo Telehandler Specs & Dimensions (2022 - 2026)

The Merlo TF 35.7 - 100 EE is a telehandler manufactured since 2022. It weighs 6.65 tons and has a transport length of 4.31 meters…

The Merlo TF 35.7 - 100 EE is a telehandler manufactured since 2022. It weighs 6.65 tons and has a transport length of 4.31 meters. The maximum reach horizontal is 3.3 meters, and it has a nominal load of 3.5 tons at the center of gravity. The lifting height is 6.6 meters, and it has a capacity of 1.35 tons at full forward reach. The travel speed is 40 km/h, and the capacity at full lift height is 3.3 tons. The transport width is 2.25 meters, and the transport height is 2.24 meters.

Telehandlers Merlo TF 35.7 - 100 EE

Technical specs - TF 35.7 - 100 EE Merlo

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
3.5 t
Model series
TF
Standard tyres
405/70-24
Max. Reach horizontal
3.3 m
Capacity at full forward reach
1.35 t
Lifting height
6.6 m
Capacity at full lift height
3.3 t
Weight
6.65 t
Transport length
4.31 m
Transport width
2.25 m
Transport height
2.24 m
Travel speed
40 km/h
Engine manuf.
Kubota
Engine type
V3800
Engine power
74 kW
Displacement
3.8 l
No. of cylinders
4
Emission level
Stage IV

More technical details, like: centre of gravity, transmission type, max. climbing ability, drive system, voltage, traction motor, hoist motor, travel speed with / without load, hoisting with / without load, lowering with load, dimension lxwxh, revolutions at max torque...

More technical details, like: centre of gravity, transmission type, max. climbing ability, drive system, voltage, traction motor, hoist motor, travel speed with / without load, hoisting with / without load, lowering with load, dimension lxwxh, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.

All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulic and shovel

Special equipment

Diesel particulate filter
No
StVZO Equipment
No
Inclination correction
No
Side displacement
No
