MT 732 Evolution Manitou Telehandler Specs & Dimensions (2007 - 2015)

The Manitou MT 732 Evolution is a telehandler manufactured from 2007 to 2015. It weighs 7.25 tons and has a maximum horizontal rea…

The Manitou MT 732 Evolution is a telehandler manufactured from 2007 to 2015. It weighs 7.25 tons and has a maximum horizontal reach of 4.16 meters. The nominal load at the center of gravity is 3.2 tons, and it can lift up to a height of 6.9 meters. At full forward reach, it has a capacity of 1.25 tons, and at full lift height, it can handle loads up to 2.8 tons. The center of gravity is located at 500 millimeters.

Telehandlers Manitou MT 732 Evolution
Telehandlers Manitou MT 732 Evolution
Telehandlers Manitou MT 732 Evolution
Telehandlers Manitou MT 732 Evolution
Telehandlers Manitou MT 732 Evolution
Telehandlers Manitou MT 732 Evolution

Visit Manitou live at

Technical specs - MT 732 Evolution Manitou

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
3.2 t
Model series
MT
Centre of gravity
500 mm
Standard tyres
400/80 -24 156 A8 TL
Transmission type
W
Max. Reach horizontal
4.16 m
Capacity at full forward reach
1.25 t
Lifting height
6.9 m
Capacity at full lift height
2.8 t
Weight
7.25 t
Engine manuf.
Perkins
Engine type
1104C-44
Engine power
61.5 kW
Displacement
4.4 l
Revolutions at max torque
2200 rpm

More technical details, like: transport length, transport width, transport height, travel speed, max. climbing ability, drive system, voltage, traction motor, hoist motor, travel speed with / without load, hoisting with / without load, lowering with load...

More technical details, like: transport length, transport width, transport height, travel speed, max. climbing ability, drive system, voltage, traction motor, hoist motor, travel speed with / without load, hoisting with / without load, lowering with load, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level, cab position, chassis type, levelling - chassis, stabilisers, drive - 2w / 4w, transmission type, telematics available, engine manufacturer, engine model, emission rating, aspiration, rated speed, engine output - gross, torque, tyre - front size, tyre - rear size, service brake - type, service brake - location, length - front of carriage, height - over cab, width - operating, wheelbase, ground clearance, width - cab, boom angle - maximum, lift height - maximum, reach - maximum, reach - at maximum lift height, reach - ground with maximum capacity, unstabilised lift height - with maximum capacity, turning radius - over tyres, lift capacity - maximum, lift capacity - to max height, lift capacity - to max reach, unstabilised lift capacity - maximum, unstabilised lift capacity - to max height, unstabilised lift capacity - to max reach, fuel tank, number of boom sections, load centre, lift capacity - fork maximum, raise time - boom, extend time - boom, speed - forward maximum, operating weight are available in the full technical specs.

All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulic and shovel

Special equipment

Diesel particulate filter
No
StVZO Equipment
No
Inclination correction
No
Side displacement
No

Download datasheets (PDF)
