TLT35D JCB Telehandler Specs & Dimensions (2009 - 2016)

Name: JCB TLT35D Telehandlers
Brand: JCB

The JCB TLT35D is a telehandler manufactured by JCB from 2009 to 2016. It weighs 5.5 tons and has a maximum horizontal reach of 2.…

The JCB TLT35D is a telehandler manufactured by JCB from 2009 to 2016. It weighs 5.5 tons and has a maximum horizontal reach of 2.45 meters. The nominal load at the center of gravity is 3.5 tons, and it can lift up to a height of 4.35 meters. At full forward reach, it has a capacity of 1.5 tons, and at full lift height, it can handle 2.75 tons. The center of gravity is located at 500 millimeters. It has a maximum climbing ability of 25 percent and can travel at a speed of 20 km/h with or without a load.

TLT35D

Years of manufacture: 2009—2016

Data sheet
Buy & Rent
Spare parts
Reviews
Transport
News

Technical specs - TLT35D JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG: 3.5 t

Model series: TLT

Centre of gravity: 500 mm

Standard tyres: 4x2

Transmission type: HY

Max. Reach horizontal: 2.45 m

Capacity at full forward reach: 1.5 t

Lifting height: 4.35 m

Capacity at full lift height: 2.75 t

Weight: 5.5 t

max. climbing ability: 25 %

Travel speed with / without load: 20 km/h

Engine manuf.: Deutz

Engine type: 2011 L04W

Engine power: 45 kW

More technical details, like: transport length, transport width, transport height, travel speed, drive system, voltage, traction motor, hoist motor, hoisting with / without load, lowering with load, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level, cab position, chassis type, levelling - chassis, stabilisers, drive - 2w / 4w, transmission type, attachment quickhitch, telematics available, platform, engine manufacturer, engine model, emission rating, aspiration, rated speed, engine output - gross, torque, tyre - front size, tyre - rear size, service brake - type, length - front of carriage, height - over cab, width - operating, wheelbase, ground clearance, lift height - maximum, reach - maximum, reach - at maximum lift height, reach - ground with maximum capacity, unstabilised lift height - with maximum capacity, turning radius - over tyres, lift capacity - maximum, lift capacity - to max height, lift capacity - to max reach, unstabilised lift capacity - maximum, unstabilised lift capacity - to max height, unstabilised lift capacity - to max reach, number of boom sections, load centre, lift capacity - fork maximum, speed - forward maximum, operating weight are available in the full technical specs.

All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulic and shovel

Special equipment

Diesel particulate filter: No
StVZO Equipment: No
Inclination correction: No
Side displacement: No

Download datasheets (PDF)
