    JCB 35-23D Specifications & Technical Data (2021-2021)

    Rate this machine now!

    Nominal load at COG: 3.5t – Centre of gravity: 500mm – Transmission type: HY – Max. Reach horizontal: 2.23m – Capacity at full forward reach: 2.3t – Lifting height: 4.4m

    Technical specs - 35-23D JCB

    Specification

    Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

    • Nominal load at COG 3.5 t
    • Centre of gravity 500 mm
    • Transmission type HY
    • Max. Reach horizontal 2.23 m
    • Capacity at full forward reach 2.3 t
    • Lifting height 4.4 m
    • Capacity at full lift hight 3.5 t
    • Weight 5.6 t
    • Transport length 3.106 m
    • Transport width 1.3 m
    • Transport height 2.22 m
    • Travel speed 20 km/h
    • Engine manuf. Kohler
    • Engine type KDI2504
    • Engine power 46 kW
    • Displacement 2.504 l
    • No. of cylinders 4
    • Emission level Stage V
    • Standard tyres ###
    • max. climbing ability ###
    • Dimension lxwxh ###
    • Revolutions at max torque ###
    • Max. torque ###
    • Cylinder bore x stroke ###

    All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulic and shovel

    Special equipment

    • Diesel particulate filter
    • StVZO Equipment
    • Inclination correction
    • Side displacement
