GTH4018 Genie Telehandler Specs & Dimensions (2013 - 2018)

Model rating
5,00 / 10

The Genie GTH4018 is a telehandler manufactured by Genie from 2013 to 2018. It has a weight of 11.98 tons and a transport length o…

The Genie GTH4018 is a telehandler manufactured by Genie from 2013 to 2018. It has a weight of 11.98 tons and a transport length of 6.57 meters. The maximum horizontal reach is 13.38 meters, and it can lift loads up to 4 tons at the nominal load center of gravity. The lifting height is 17.61 meters, and it has a capacity of 0.7 tons at full forward reach. The center of gravity is located at 890 millimeters. It has a travel speed of 27 kilometers per hour. The capacity at full lift height is 4 tons. The transport width is 2.42 meters, and the transport height is 2.44 meters.

Telehandlers Genie GTH4018
Telehandlers Genie GTH4018
Telehandlers Genie GTH4018
Telehandlers Genie GTH4018
Telehandlers Genie GTH4018
Telehandlers Genie GTH4018

Technical specs - GTH4018 Genie

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
4 t
Centre of gravity
890 mm
Standard tyres
405/70-24
Transmission type
HY
Max. Reach horizontal
13.38 m
Capacity at full forward reach
0.7 t
Lifting height
17.61 m
Capacity at full lift height
4 t
Weight
11.98 t
Transport length
6.57 m
Transport width
2.42 m
Transport height
2.44 m
Travel speed
27 km/h
Engine manuf.
Perkins
Engine type
854E-34TA
Engine power
75 kW
Displacement
3.4 l
Max. torque
430/1400 Nm
Emission level
IV

More technical details, like: model series, max. climbing ability, drive system, voltage, traction motor, hoist motor, travel speed with / without load, hoisting with / without load, lowering with load, dimension lxwxh, revolutions at max torque, no. of cylinders...

More technical details, like: model series, max. climbing ability, drive system, voltage, traction motor, hoist motor, travel speed with / without load, hoisting with / without load, lowering with load, dimension lxwxh, revolutions at max torque, no. of cylinders, cylinder bore x stroke, cab position, chassis type, levelling - chassis, stabilisers, drive - 2w / 4w, transmission type, attachment quickhitch, telematics available, engine manufacturer, engine model, emission rating, aspiration, rated speed, engine output - gross, tyre - front size, tyre - rear size, tyre 2 - front size option, tyre 2 - rear size option, service brake - type, service brake - location, length - at ground, length - front of carriage, height - over cab, width - operating, wheelbase, ground clearance, width - cab, width - stabiliser spread, boom angle - maximum, lift height - maximum, reach - maximum, reach - at maximum lift height, reach - ground with maximum capacity, unstabilised lift height - with maximum capacity, stabilised lift height - with maximum capacity, breakout force, lift capacity - maximum, lift capacity - to max height, lift capacity - to max reach, unstabilised lift capacity - maximum, unstabilised lift capacity - to max height, unstabilised lift capacity - to max reach, stabilised lift capacity - maximum, stabilised lift capacity - to max height, stabilised lift capacity - to max reach, fuel tank, number of boom sections, load centre, lift capacity - fork maximum, raise time - boom, extend time - boom, speed - forward maximum, speed - reverse maximum, operating weight are available in the full technical specs.

All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulic and shovel

Special equipment

Diesel particulate filter
No
StVZO Equipment
No
Inclination correction
No
Side displacement
No
