Scorpion 6030 Claas Telehandler Specs & Dimensions (2013 - 2017)

Name: Claas Scorpion 6030 Telehandlers
Brand: Claas

The Claas Scorpion 6030 telehandler, manufactured from 2013 to 2017, weighs 6.2 tons and has a transport length of 4.58 meters. It…

The Claas Scorpion 6030 telehandler, manufactured from 2013 to 2017, weighs 6.2 tons and has a transport length of 4.58 meters. It has a maximum horizontal reach of 3.28 meters and a lifting height of 6.15 meters. The telehandler has a nominal load capacity of 3 tons at the center of gravity, and a capacity of 1.2 tons at full forward reach. The center of gravity is located at 500 millimeters. It has a travel speed of 40 km/h. The capacity at full lift height is 1.68 tons. The transport width is 2.28 meters and the transport height is 2.31 meters.

Scorpion 6030

Years of manufacture: 2013—2017

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - Scorpion 6030 Claas

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG: 3 t

Model series: Scorpion

Centre of gravity: 500 mm

Standard tyres: 405/70-20 MPT

Max. Reach horizontal: 3.28 m

Capacity at full forward reach: 1.2 t

Lifting height: 6.15 m

Capacity at full lift height: 1.68 t

Weight: 6.2 t

Transport length: 4.58 m

Transport width: 2.28 m

Transport height: 2.31 m

Travel speed: 40 km/h

Engine manuf.: Deutz

Engine type: TCD3.6

Engine power: 90 kW

More technical details, like: transmission type, max. climbing ability, drive system, voltage, traction motor, hoist motor, travel speed with / without load, hoisting with / without load, lowering with load, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level, cab position, chassis type, levelling - chassis, stabilisers, drive - 2w / 4w, transmission type, engine manufacturer, engine model, aspiration, rated speed, engine output - net, tyre - front size, tyre - rear size, tyre 2 - front size option, tyre 2 - rear size option, service brake - type, service brake - location, length - front of carriage, height - over cab, width - operating, wheelbase, ground clearance, width - cab, boom angle - maximum, lift height - maximum, reach - maximum, reach - at maximum lift height, unstabilised lift height - with maximum capacity, turning radius - over tyres, lift capacity - maximum, lift capacity - to max height, lift capacity - to max reach, unstabilised lift capacity - maximum, unstabilised lift capacity - to max height, unstabilised lift capacity - to max reach, fuel tank, number of boom sections, load centre, lift capacity - fork maximum, speed - forward maximum, operating weight are available in the full technical specs.

All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulic and shovel

Special equipment

Diesel particulate filter: No
StVZO Equipment: No
Inclination correction: No
Side displacement: No

Download datasheets (PDF)

Scorpion 6030 Claas Specification for Europe (DE)
