T 306 H Ausa Telehandler Specs & Dimensions (2009 - 2017)

Name: Ausa T 306 H Telehandlers
Brand: Ausa

The Ausa T 306 H is a telehandler manufactured from 2009 to 2017. It has a weight of 5.4 tons and a transport length of 5.244 mete…

The Ausa T 306 H is a telehandler manufactured from 2009 to 2017. It has a weight of 5.4 tons and a transport length of 5.244 meters. With a maximum horizontal reach of 3.41 meters, it can lift a nominal load of 3 tons at the center of gravity, and has a lifting height of 6.1 meters. At full forward reach, it has a capacity of 1 ton, and at full lift height, it can handle 3 tons. The telehandler has a center of gravity at 500 millimeters and a travel speed of 24 km/h. Its transport width is 2.015 meters and transport height is 2.07 meters.

T 306 H

Years of manufacture: 2009—2017

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - T 306 H Ausa

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG: 3 t

Model series: T

Centre of gravity: 500 mm

Transmission type: HY

Max. Reach horizontal: 3.41 m

Capacity at full forward reach: 1 t

Lifting height: 6.1 m

Capacity at full lift height: 3 t

Weight: 5.4 t

Transport length: 5.244 m

Transport width: 2.015 m

Transport height: 2.07 m

Travel speed: 24 km/h

Engine manuf.: Kubota

Engine type: V3600

Engine power: 62.3 kW

More technical details, like: standard tyres, max. climbing ability, drive system, voltage, traction motor, hoist motor, travel speed with / without load, hoisting with / without load, lowering with load, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level, cab position, chassis type, levelling - chassis, stabilisers, drive - 2w / 4w, transmission type, telematics available, engine manufacturer, engine model, emission rating, aspiration, engine output - gross, tyre - front size, tyre - rear size, service brake - type, service brake - location, length - front of carriage, height - over cab, width - operating, wheelbase, ground clearance, boom angle - maximum, lift height - maximum, reach - maximum, reach - at maximum lift height, reach - ground with maximum capacity, unstabilised lift height - with maximum capacity, turning radius - over tyres, lift capacity - maximum, lift capacity - to max height, lift capacity - to max reach, unstabilised lift capacity - maximum, unstabilised lift capacity - to max height, unstabilised lift capacity - to max reach, fuel tank, number of boom sections, load centre, speed - forward maximum, operating weight are available in the full technical specs.

All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulic and shovel

Special equipment

Diesel particulate filter: No
StVZO Equipment: No
Inclination correction: No
Side displacement: No
