H60T EVO Linde LPG Forklift Specs & Dimensions (2023 - 2026)

Nominal load at COG: 6t – Centre of gravity: 600mm – Standard tyres: SE 2x/2 – Transmission type: HY – Weight: 10.031t – Total wid…

Nominal load at COG: 6t – Centre of gravity: 600mm – Standard tyres: SE 2x/2 – Transmission type: HY – Weight: 10.031t – Total width: 1900mm

Linde is the manufacturer of the H60T EVO LPG forklift. The production years for this model are (2023 - 2026). Find here detailed specs for H60T EVO LPG powered lift truck - in a form of table chart below and downloadable datasheet. Explore also the other forklift models produced by Linde.

LPG Forklifts Linde H60T EVO
LPG Forklifts Linde H60T EVO
LPG Forklifts Linde H60T EVO
LPG Forklifts Linde H60T EVO
LPG Forklifts Linde H60T EVO
LPG Forklifts Linde H60T EVO
LPG Forklifts Linde H60T EVO
LPG Forklifts Linde H60T EVO
LPG Forklifts Linde H60T EVO
LPG Forklifts Linde H60T EVO
LPG Forklifts Linde H60T EVO
LPG Forklifts Linde H60T EVO

Technical specs - H60T EVO Linde

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Nominal load at COG
6 t
Centre of gravity
600 mm
Standard tyres
SE 2x/2
Transmission type
HY
Weight
10.031 t
Total width
1900 mm
Construction height
2746 mm
Turning radius
3.186 m
Lifting height
3.55 m
Travel speed with / without load
22/23 km/h
Hoisting with / without load
0,51/0,53 m/s
Lowering with load
0.5 m/s
max. climbing ability
35 %
Engine manuf.
VW
Engine type
CKPA
Engine power
72 kW
Displacement
3.597 l
Revolutions at max torque
2500 rpm
No. of cylinders
6

More technical details, like: model series, dimension lxwxh, max. torque, cylinder bore x stroke, emission level are available in the full technical specs.

L = pneumatic tyres, x = drive, SE = superelastic, P = PUR (Elastollan, Vulkollan), V = solid rubber, ND = low pressure tyres, 3 = three-wheel, 4 = four-wheel, 6 = six-wheel All specifications and prices refer to basic models with standard fork carrier, 2 standard prongs, without additional hydraulics with Simplex mast (3,3m up to 10t • 5m > 10t load capacity)

Download datasheets (PDF)

Linde H60T EVO overview

Drive

Reliability

Proven in tough applications, the decoupling of mast and drive axle with chassis and mast tilt results in reduced shock and vibration. The enclosed motor and drive units are designed for maximum strength and durability. Reliable, fast maintenance helps to keep the trucks and their operators out where the work gets done.


Safety

Safety

The Linde Protector Frame protects the operator with a strong, enclosed roof structure and the Linde Load Control provides precise load handling. The Linde twin-pedal control and dual-circuit braking system ensure safe operation. The Linde Curve Assist reduces speed when cornering, enhancing safety and stability in all driving conditions. The compact design and excellent all-round visibility provide the operator with a clear view of the working environment, further enhancing safety.


Performance

The powerful engine and exhaust system deliver impressive performance, allowing for fast acceleration and high top speeds. The advanced engine and drive technology, combined with the Linde Load Control system, enable the operator to handle tasks quickly and efficiently. The hydrostatic drive ensures precise control and smooth operation, making it possible to maneuver in tight spaces. Precise steering control allows for easy handling.


Productivity

The variety of attachments and options for the Linde hydrostatic drive forklift trucks facilitate specific application needs. The Linde Load Control allows for precise and efficient load handling, increasing productivity. The ergonomic design of the operator's compartment ensures comfort and reduces fatigue, allowing for longer working hours. The compact design and excellent all-round visibility make it easier to maneuver in tight spaces, further enhancing productivity.
